ML21 Auto Flexible Straw Making Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	Marrow
Model Number	ML21

Product Description

Specifications

ML21 flexible straw auto making machine is a machine of making flexible drinking straws.

ML21 PP FLEXIBLE STRAW AUTO MAKING MACHINE

DESCRIPTION

Model ML21 flexible straw auto making machine is a machine of making flexible drinking straws. The straight straws supplied in the hopper at the top of machine ,passes through 12 sets of conveyor and 12 sets of needle and 1 sets of shaping wheel,delivered to output conveyor automatically.

TECHNICAL FEATURE

1. High efficiency and high production rate,

2. Automatic product counting,

3. Automatic stop in the event of straw jamming,

4. Hopper in stainless steel is set at conveyor,one man can operate two machines,

5. Special repairing safety button ,

SPECIFICATIONS

Model		ML21-4	ML21-5	ML21-6
Capability		250∼280pcs/min
Main motor		1.5kW (VFD)
Specifications of straw	Diameter	φ3.8mm	φ4.8mm		φ5.8mm
	Length of straight straw	155∼245mm	190∼260 mm		190∼260 mm
	Length of flexible straw	140∼235 mm	175∼245 mm		175∼245 mm
	Thickness of straw	0.18±0.02 mm	0.16±0.02 mm		0.16±0.02 mm
	Top section length	30∼50 mm
	Length of flexible part	8∼11 mm
Other specifications are customizable
