VT12 series projector screen diameter 308mm. screen rotary range 0~360 degree, digital optical profile projector price

FOB Price

USD $1 - $3,800 / Set

1 Set(Min.Order)

Port any port of China
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Beijing, China		Brand Name	HUATEC
Model Number	VT12 series

Product Description

Uses and Features:

Profile Projector VT12 series are precise and excellent effective measuring instrument integrating Optic, Mechanic, Electricity, and Computer technology.

It is widely used in the field of mechanic, electronic, rubber industry, and college, research institute and the measuring checking department for checking product quality. VT12 can inspect all kinds of surface and outline of complicated work-pieces such as Template, Pressing work-pieces, Cam, Screw thread, Gear, etc.

Technical Specification:

The Technical Specification of Profile Projector VT12 series (Unit: mm)
1,Model	VT12-1550T		VT12-2010T
2,Stage Travel: X and Y-axis	150×50		200×100
3,Metal stage dimension	340×152		350×170
4,Glass Stage Dimension	196×96		246×120
5,Resolution of X and Y-scale	0.001
6,Travel: Z axis	90 (for focusing)
7,Screen diameter	Ø308, effective range≥Ø300mm
8,Rotary range of screen	0~360°
9 Resolution of Rotary Indicator	1'/0.01°
10,Accuracy	≤4+L/50 (um)
11,Objective magnification	10X(Std.)	20X(Opt.)	50X(Opt.)	100X(Opt.)
12,Object view-field	30	15	6	3
13,Work distance	78.33	44.30	24.50	25.30
14,Data Processor	Multifunctional LED Digital Readout DC 3000
15,Instrument Illumination	Surface and Contour Illumination: 24V/150W halogen lamp
16,Power	110V/ 220V(AC), 50/60HZ
17,Dimension (D× W × H)	770 × 550 × 1100/770 × 810 × 1120
18,Instrument Weight	130Kg	170Kg	130Kg	170Kg
