220T Good Horizontal Injection Molding Machine H220SD

FOB Price

USD $1,500 - $80,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Preform Injection
Style	Horizontal	Brand Name	Qianke
Model Number	H220SD	Place of Origin	Guangdong, China
Plastic Type	Thermoplastic	Automatic	Yes
Injection Weight	382-570g	Injection Rate	130-205mm/s
Clamping Force	220Tf, 120-500Ton	Opening Stroke	450mm
Certification	CE	After-sales Service Provided	Overseas service center available

1.Clamping force120-500tons
2.Vertical clamping,Vertical injection,easy to insert
3.Famous brand in each parts.
4.Yuken,Omron

1,Specifications

			Unit	H220SD
Injection Unit	Screw Diameter		mm	45 50 55
	Theoretical Injection Volume		cm3	382 471 570
	Injection Weight(PS)		g(oz)	355(12.5) 438(15.4) 530(18.7)
	Max.Injection Pressure		Mpa(kgf/cm2)	244(2489) 198(2016) 163(1666)
	Injection Rate		cm3/s	207 255 309
	Injection Speed		mm/s	205 165 130
	Screw Speed Rotation		r.p.m	0-220
Clamping Unit	Clamping Force		KN(tf)	2156(220)
	Clamping Stroke		mm	450
	Min.Mold Thickness		mm	350
	Max.Opening		mm	800
	Distance Between Tie Bars		mm	910*450
	Max.Mould Size		mm	650*620
	Diameter of Rotary Table		mm	---
	Ejector Distance		mm	125
	Ejector Force		KN(tf)	56.8(5.8)
Others	System Pressure		Mpa(kgf/cm2)	17.2(175)
	Oil Tank Capacity		L	580
	Electric Power		KW(HP)	30(40)
	Heater Power		KW	13
	Machine Dimensions	L*W	mm	4625*2450
		H	mm	3320
	Machine Weight		tf	13

2,Pictures
