Double slides plastic injection machine 2 sliders working table high efficiency
- 15 Set / Sets per Month
- Zhongshan
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Preform Injection | |
| Style | Vertical | Brand Name | YaTai | |
| Model Number | V120SD | Place of Origin | Guangdong, China | |
| Plastic Type | Thermoplastic | Automatic | Yes | |
| Injection Weight | 151-236g | Injection Rate | 112-172mm/s | |
| Clamping Force | 120ton, 120ton | Opening Stroke | 560-660mm | |
| Power(W) | 29.2kw | Certification | ISO9001,CE | |
| After-sales Service Provided | Overseas service center available |
Product Description
| Model No. | V120SD | |||||
Injection Unit | Screw Diameter | mm | 36 | 40 | 45 | |
| Theoretical Injection Volume | cm3 | 162 | 201 | 254 | ||
| Injection Weight(PS) | g(oz) | 151(5.3) | 187(6.6) | 236(8.3) | ||
| Max.Injection Pressure | Mpa(kgf/cm2) | 222(2268) | 180(1838) | 142(1452) | ||
| Injection Rate | cm3/s | 114 | 140 | 178 | ||
| Injection Speed | mm/s | 112(172) | ||||
| Screw Speed Rotation | r.p.m | 0-300 | ||||
| Nozzle Out From Platens | mm | ≥45 | ||||
Clamping Unit | Clamping Force | KN(tf) | 1176(120) | |||
| Clamping Stroke | mm | 280 | ||||
| Min.Mold Thickness | mm | 280(380) | ||||
| Max.Opening | mm | 560(660) | ||||
| Distance Between Tie Bars | mm | 760*380 | ||||
| Max.Mould Size | mm | 580*540 | ||||
| Platen/Slide Size | mm | 1290*560 | ||||
| Ejector Distance | mm | 100 | ||||
| Ejector Force | KN(tf) | 45(4.6) | ||||
| Others | System Pressure | Mpa(kgf/cm2) | 13.7(140) | |||
| Oil Tank Capacity | L | 340 | ||||
| Electric Power | KW(HP) | 18.5(25) | ||||
| Heater Power | KW | 10.7 | ||||
| Machine Dimensions | L*W | mm | 2126*1980 | |||
| H | mm | 3205(4045) | ||||
| Machine Weight | tf | 5.8 | ||||
2. We will arrange to manufacture the second day after confirmation,we can delivery it usually after 35 days
3. According to the destination,we will compare several transportation companies and select the most suitable and economic one to provide service for us
1. Provide free guidance of before you start use our injection molding machine
2. 1 year warranty
3. Free remote guidance by video chat when you have problem during use the injection molding machine
Zhongshan Yatai Machinery Co., Ltd. is biggest wire processing factory in the area of the perl river delta region ,Specialized in R&D and producing plastic injection molding machine, full auto wire stripping crimping machines, cutting stripping machines, tube cutting machines and automatic robot hands.If you want to know more about our pruducts,please browse the website as follows
