85T Good Vertical LSR Injection Molding Machine V85R2-LSR
US$ 1,500 - 80,000
/ Set
1 Set(Min. Order)
- Zhongshan
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
120T Good Vertical LSR Injection Molding Machine V120S-LSR
-
55T Good Vertical LSR Injection Molding Machine V55SD-LSR
-
Rotary Injection Molding Machine Full Automatic Produce LED Lamp Bulb Base Quality Choice
-
Horizontal Injection Vertical Clamping Injection Molding Machine
-
2015 New Plastic Injection Molding Machine
-
Plastic Injection Moulding Machine Sliding Table
Product Details
| Condition | New | Type | Preform Injection | |
| Style | Vertical | Brand Name | Qianke | |
| Model Number | V85R2-LSR | Place of Origin | Guangdong, China | |
| Plastic Type | Thermoplastic | Automatic | Yes | |
| Injection Weight | 223cm3 | Injection Rate | 107mm/s | |
| Clamping Force | 85Tf, 35-200Ton | Opening Stroke | 250mm | |
| Certification | CE | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
1.Clamping force 35-200tons2.Vertical clamping,Vertical injection,easy to insert
3.Famous brand in each parts.
4.Yuken,Omron
1,Specifications
| Unit | V85R2-LSR | |||||
| Injection Unit | Screw Diameter | mm | 40 | 45 | ||
| Theoretical Injection Volume | cm3 | 176 | 223 | |||
| Max.Injection Pressure | Mpa(kgf/cm2) | 146(1492) | 115(1176) | |||
| Injection Rate | cm3/s | 134 | 170 | |||
| Injection Speed | mm/s | 107 | ||||
| Screw Speed Rotation | r.p.m | 0-300 | ||||
| Nozzle Out From Platens | mm | ≥45 | ||||
| Clamping Unit | Clamping Force | KN(tf) | 833(85) | |||
| Clamping Stroke | mm | 250 | ||||
| Min.Mold Thickness | mm | 170(270) | ||||
| Max.Opening | mm | 420(520) | ||||
| Distance Between Tie Bars | mm | 500*385 | 658*335 | --- | ||
| Max.Mould Size | mm | 550*470 | 500*475 | 340*340 | ||
| Platen/Slide Size | mm | 620*490 | 1135*495 | 980 | ||
| Ejector Distance | mm | 75 | 75 | 75 | ||
| Ejector Force | KN(tf) | 26.5(2.7 | 26.5(2.7) | 45(4.6) | ||
| Others | System Pressure | Mpa(kgf/cm2) | 13.7(140) | 13.7(140) | 13.7(140) | |
| Oil Tank Capacity | L | 280 | 280 | 310 | ||
| Electric Power | KW(HP) | 15(20) | 15(20) | 15(20) | ||
| Machine Dimensions | L*W | mm | 2140*1410 | 2090*1700 | 2145*1772 | |
| H | mm | 2736(3456) | 2730(3470) | 2760(3500) | ||
| Machine Weight | tf | 3.35 | 3.7 | 4.3 | ||
2,Pictures
