ZLJ5416THB 52-6RZ Truck-Mounted Concrete Pump
- SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Power Type | Diesel | |
| Place of Origin | Hunan, China | Brand Name | LIONKIN-ZOOMLION | |
| Model Number | ZLJ5331THB 43X-5Z | Power(W) | 287kw | |
| Weight | 40000kg | Dimension(L*W*H) | 13125x2500x4000 | |
| Certification | EUROIII |
Product Description
Specifications
We can supply 22m ,37m ,40m ,43m ,49m ,52m Truck-mounted concrete pump1. Main technology parameter
Model | ZLJ5416THB 52-6RZ | ||
Pumping system | Max. Theor. output | m3/h | 150 |
Max. Theor. concrete output Pressure | MPa | 8.5 | |
Rated working pressure | MPa | 35 | |
Pumping frequency | min-1 | 23 | |
Hopper capacity | L | 600 | |
Filling height | mm | 1540 | |
Hydraulic system type |
| Close loop | |
Distribution valve |
| S valve | |
Oil cylinder dia.×stroke | mm | φ130×2100 | |
Concrete cylinder dia.×stroke | mm | φ260×2100 | |
Hydraulic oil cooling |
| Air cooling | |
Recommended concrete slump | cm | 12~23 | |
Max. aggregate dimension | mm | 40 | |
Placing boom | Structure type |
| 52-6RZ |
Placing depth | m | 52 | |
Horizontal distance | m | 47 | |
Placing depth | m | 37.3 | |
Slewing angle |
| ±270° | |
Boom number |
| 5 | |
The length of boom section | mm | 10710/8420/8090/10180/6100/4500 | |
Sections folding angle |
| 90°/180°/180°/240°/250°/90° | |
Pipe diameter | mm | 125 | |
End hose length | mm | 3000 | |
Min. height of opening placing boom | mm | 13320 | |
Outriggers span (front×rear×side) | mm | 10715×10535×10660 | |
Chassis and the whole machine | Chassis model |
| CYH51Y 8×4 |
Wheelbase | mm | 1850+4605+1310 | |
Engine type |
| 6WF1D | |
Engine power | kW/(r/min) | 287/1800 | |
Engine moment | N.m/(r/min) | 1863/1100 | |
Maximum displacement | cc | 14256 | |
Oil tank cubage | L | 400 | |
Tail gas exhaust standard |
| Euro. Ⅲ | |
otal weight | kg | 40000 | |
Overall dimensions | mm | 13125×2500×4000 | |
Others | Lubrication mode |
| Automatic lubrication |
Oil tank volume | L | 800 | |
Control mode |
| Manual+ remote control | |
Maximum water pressure | MPa | 7 | |
Water tank volume | L | 400 | |
Pipe cleaning mode |
| Water cleaning/dry cleaning | |
The 52m truck-mounted concrete pump adopts BENZ chassis,ISUZU chassis, and so on.
| 5.Main components | |||
| 5.1 Main assembly components | |||
| SN | Name | Company | Country |
| 1 | Chassis | ISUZU | Japan |
| 2 | Placing boom | ZOOMLION | CHINA |
| 3 | Base structure and outrigger | ZOOMLION | CHINA |
| 4 | Swivel reducer | Italy | |
| 5 | Remote control | HBC/NBB/HETRNIC | Germany |
| 6 | Transfer box | Germany | |
| 5.2 Main assemblies of hydraulic system | ||
| SN | Name | Manufacturer |
| 1 | Hydraulic pumps group | REXROTH/KPM |
| 2 | Hydraulic pump of placing boom | REXROTH/PSM |
| 3 | Hydraulic valve | REXROTH |
| 4 | Multi- valve of placing boom | HAWE/ REXROTH |
| 5 | Multi- valve of outrigger | Italy Oil control |
| 6 | Balance valve | HAWE/LUEN |
| 7 | Mixing motor | EATON |
| 8 | Oil filter | Italy MP/ Germany INTERNOMAN |
| 5.3 Main assemblies of electric system | |||
| SN | Name | Trademark | Note |
| 1 | Control | IFM | German |
| 2 | Coder | P+F | German |
| 3 | Touch screen | Schneider | France |
| 4 | Relay | Schneider | France |
| 5 | Switch | Schneider | France |
| 6 | Breaker | Schneider | France |
| 7 | Sensor | Danfoss | Denmark |
