Product Details
| Place of Origin | Shandong, China | Brand Name | HENRYD | |
| Model Number | 6m-30m | Type | Other, wind turbine tower |
Product Description
Tower/pole for wind turbine/wind generator
1.free stand tower/independance tower/stand alone tower
Including tower, base plate, ground screws, adjustable nuts...
Several parts of the tower connecting by flange. We provide tower foundation drawing.
Provide customized made service.
The installation needs crane. Small installation area, safety and reliable
When delivery, we can insert several parts of tower together to save delivery cost.
Normally for 300w-100kw wind turbine.
Tower height: we can manufacture according to your customer request.
| Wind turbine model | Height & Thickness | Parts |
| FD2.5-500w | 6m, thickness 4mm | 1 |
| FD2.2-300w & FD2.5-500w | 8m thickness 3.5mm tilting up tower | 2 |
| 9m thickness 3.5mm tilting up tower | 2 | |
| 12m thickness 3.5mm tilting up tower | 2 | |
| D-2.8M | 1kw 7m thickness 3.5mm | 1 |
| 1kw 8m thickness 4mm | 2 | |
| 1kw 9m thickness 4mm | 2 | |
| 1kw 10m thickness 4mm | 2 | |
| D-2.8M & D-3.2M | 1kw-2kw 9m thickness 4mm tilting up tower | 2 |
| FD3.8 & FD3.2 | 2kw 7m thickness 4mm | 2 |
| 2k8m thickness 4mm hydraulic tower(including hinge base and hydraulic system) | 2 | |
| 2kw 6m thickness 4mm tilting up tower | 2 | |
| 2kw 7m thickness 4mm tilting up tower | 2 | |
| 2kw 8m thickness 4mm tilting up tower | 2 | |
| 2kw 9m thickness 4mm | 2 | |
| 2kw 10m thickness 4mm | 2 | |
| 2kw 12m thickness 4mm | 2 | |
| 2kw 15m thickness 4mm | 3 | |
| 2kw 10m thickness 4mm tilting up tower | 2 | |
| 2kw 12m thickness 4mm tilting up tower | 2 | |
| D-4M | 3kw 8m thickness 5mm | 2 |
| 3kw 10m thickness 5mm | 2 | |
| D-5M,D-6M | 5kw 8m thickness 5m chain pole | 2 |
| 5kw 12m thickness 5mm | 2 | |
| 5kw 13m thickness 5mm | 2 | |
| 5kw 15m thickness 5mm | 3 | |
| 5kw 18m thickness 6mm (base plate φ1030) | 2 | |
| 5kw 7m thickness 5mm tilting up tower(base plate φ700) | 2 | |
| 5kw 8m thickness 5mm tilting up tower | 2 | |
| 5kw 10m thickness 5mm tilting up tower | 2 | |
| 5kw 12m thickness 5mm tilting up tower | 2 | |
| 5kw 13m thickness 5mm tilting up tower | 2 | |
| 5kw 20m stand alone tower, 6mm | ||
| 5kw 15m thickness 5mm tilting up tower | 2 | |
| D-8M | 10kw 12m thickness 6mm(base plate φ1055) | 2 |
| D-10M & D-12M | 20kw 11m thickness 6mm(base plate φ1055) | 2 |
| 20kw 15m thickness 6mm | 3 | |
| 20kw 15m thickness 8mm | 3 | |
| 20kw 18m thickness 6mm | 3 | |
| 20kw 18m thickness 6mm(without plate form, ladder) | 3 | |
| 20kw 20m thickness 6mm | 2 | |
| 20kw 24m thickness 8mm | 3 | |
| 20kw 25m thickness 8mm | 3 | |
| 20kw 28m thickness 12mm | 4 | |
| 20kw 30m thickness 12mm | 4 | |
| 20kw 35m thickness 12mm | 4 |
2. guy wire tower with accessory for wind turbine
Including tower, base plate, guy wires, anchors...
Several parts of the tower insert together by sleeves. We provide tower foundation drawing.
Provide customized made service.
The installation needs chain block or crane. Larger installation area, safety and reliable
Delivery cost is lower;
Normally for 300w-10kw wind turbine.
Tower height: we can manufacture according to your customer request.
| Wind turbine blades diameter | Tower spec | Tower height |
| D-2.2m | Φ60 vertical axis,2parts | 6m |
| Φ76 vertical axis,3parts | 6m | |
| Φ76 vertical axis,4parts | 6m | |
| D-2.5m | Φ60 vertical axis,2parts | 6m |
| Φ76 vertical axis,3parts | 6m | |
| Φ76 vertical axis,4parts | 6m | |
| Φ89 vertical axis,2parts | 12m | |
| D-2.8m | Φ76 vertical axis,2parts | 6m |
| Φ76 vertical axis,2parts | 8m | |
| Φ76 vertical axis,2parts | 9m | |
| D-3.2m | Φ89 vertical axis,2parts | 9m |
| Φ76 89,2parts | 12m | |
| D-4m/5m | Φ165 2parts | 8m |
| Φ165 2parts | 9m | |
| Φ165 2parts | 12m |
3. hydraulic tower for wind turbine
Including towers, tower base, ground screws, hydraulic system...
Several parts of the tower connecting by flange. We provide tower foundation drawing.
Provide customized made service.
The installation no need crane again. Small installation area, safety and reliable.
But the cost is higher. For small quantity order, we did not recommend this tower.
When delivery, we can insert several parts of tower together to save delivery cost.
Normally for 300w-50kw wind turbine.
Tower height: 8m-30m, or manufacture according to your customer request.
4. tilting up tower (folding tower) for 300w-5kw wind turbine
Including towers, base plate, ground screws,adjustable nuts...
Several parts of the tower connecting by flange. We provide tower foundation drawing.
Provide customized made service.
The installation no need crane again. Small installation area, safety and reliable.
But the cost is higher than stand aone tower.
Normally for 300w-50kw wind turbine.
Tower height: 6m-15m, or manufacture according to your customer request.
5. Advantage
1.) Meintenance free design
2. )CE,ISO approved
3.) Easy assembly and installation
4.) Delivery within 15 working days after confirmation
5).Tower type and tower height can be made according to user's request
Normal height is: 6m,8m,9m,10m,12m,15m,18m,25m,27m,30m for 300w-30kw wind turbine generator
We can manufacture according to your request or wind generator technical data.
6.) Warranty: 5 years after installation
7.) Material and antisepsis
manganese steel material. Hot galvanization, then coated or painted.
8.) Package: softpackage
For more details, pls contact with us.
Towers are packed in soft packages. we try to insert them together when delivery to save delivery cost.
All the accessory will be put into one plywood case to avoid losing.
Normally we delivery the products by sea. If you need us check the delivery cost, pls let us know the destination port to you. Then we will check the delivery cost accordingly.
Provide CIF,FOB service.
Provide professional wind turbine technical support;
Provide on/off grid system design, wind solar hybrid system design service.
Completely system provider and designer;
Wind turbine type, model, capacity selection professional support;
Tower design, foundation drawing support;
Provide Pma, hub, flange drawing;
Provide OEM service, customized service.
Support paypal /west union payment, TT payment;
We started to manufacture wind turbine in 1994. In 2004, there are only 4 small wind turbine manufactures in China. We keep improving and develop in the small wind turbine field. We are not the leading small wind turbine exporter, but we are the leading wind turbine manufacture and designer now.
We manufacture 300w-30kw fixed pitch wind turbine;
2kw, 3kw, 5kw, 10kw, 20kw, 30kw, 50kw, 60kw pitch controlled wind turbine;
1kw, 2kw, 3kw, 5kw Vertical axis wind turbine;
On grid system/off grid system, wind solar hybrid system; Water heating system;
For more details, pls contact with us via e-mail.
1. Wind turbine model selection
It depends your local annual average wind speed, daily/monthly home power consumption.
Low average wind speed place, select larger blades rotor, higher rated working voltage;
Rich wind place select speed limited wind turbine: variable pitch wind turbine, stall out vertical axis wind turbine.
The safety and steady working system is the first choice.
2. Wind turbine tower selection
Now we have guy wire tower, stand alone tower, tilting up tower, hydraulic tower.
Guy wire tower cost is lower, easy to delivery. But the installation area is larger;
Tilting up tower is for 500w-5kw wind turbine. Easy installation, small installation area. But the delivery cost is higher.
Hydraulic tower: It is used for no crane place. Easy installation and put down. The cost is higher.
Stand alone tower for the installation place with crane.
The tower height: Make sure blades rotor is higher than wind turbine surrounding barrier height.
3. Working system selection
On grid system: wind turbine with tower + PWM controller with dump load + grid tie inverter;
Off grid system: wind turbine with tower + PWM charge controller with dump load + battery group + inverter;
Wind solar hybrid on/off grid system: Safety and reliable than only wind or solar system.
Wind turbine water heating system: work in rich wind place. Average wind speed higher than 8m/s.
For more question, pls contact with us directly. We will give you a professional response.
Why select us:
We are the wind turbine designer and manufacture. We know our wind turbine advantage and disadvantage in different wind condition.
I have more than 10 years wind turbine sales experience. We provide the right wind turbine and working system to different user according to their different situation and request.
In 2004, there are 4 small wind turbine manufacture. Now there are so much trading company and manufacture, we know Chinese small wind turbine market well and can provide user more useful advise.
