16 ports Managed Full Gigabit Industrial Ethernet Switch with 4 SFP Sockets

       IES7120G-4GS is an industrial grade, managed and redundancy Ethernet switch which supports 16 Gigabit Ethernet Ports and 4 Gigabit SFP slots. It provided some kinds of advanced network managed function, like as: SW-Ring redundancy ring network, VLAN, Trunking, Quality of Service, Speed control, port mirroring, fault alarm and firmware upgrade online. SW-Ring can bring your Ethernet to intelligent redundancy. Standard Industry design, can satisfied every requirement of the industry scene. All components used industry grade, it takes products high reliability. It provided wide voltage power supply input.
      Product accorded to CE, FCC standard and Industry grade 4 design requirement, support 2 channel DC power input and 1 channel relay alarm output, and -40~75℃ working temperature, can meet all kinds of Industrial environment requirement and provide the solution of the economy.

Switch

Properties

Forward speed: 1488100pps

Maximum filter speed: 1488100pps
Transmit mode: store and forward
Backplane bandwidth: 56Gbps
MAC table size: 10K
Buffer size: 12M

Electrical Port: RJ45 Connector, 10/100/1000Base-T(X) auto negotiation, full/half duplex, MDI/MDI-X auto detect

Gigabit SFP Port: 1000Base-FX(LC connector)

Console port: RS-232(RJ45 Connector) debug serial port

Alarm port: 1 channel relay alarm output( 2 bit terminal block)

Power port: 2 channel power iutput( 4 bit terminal block)

10/100/1000Base-T(X):CAT5/CAT5e UTP(≤100m)

1000Base-FX:Optical Fiber

Multi-mode:    1310nm, 2Km
Single-mode: 1310nm, 20/40/60Km
                          1550nm, 80/100/120Km

wavelength: 1310nm, 1550nm

Run indicator: RUN
Interface indicator: Link (G1~G20)
Power supply indicator: P1, P2
Alarm indicator: ALM

Input Voltage: 12~48VDC
Type of input: 4 bits terminal block
DC support reverse connection
DC support redundant power supply
No-load consumption: 11.04W@48VDC
Full-load consumption: 14.88W@48VDC

Shell: IP40 protection grade, metal shell
Size(W×H×D): 160mm×130mm×70mm

Installation: DIN rail mounted

EMI:

FCC Part 15, CISPR (EN55022) class A
EMS:

EN61000-4-2 (ESD), Leve 4
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 4
EN61000-4-5 (Surge), Level 4
EN61000-4-6 (CS), Level 3
EN61000-4-8, Level 5
Shock:

IEC 60068-2-27
Free fall:

IEC 60068-2-32
Vibration:

IEC 60068-2-6

1. Industrial Ethernet Switch IES7120G-4GS (plus terminal block)  × 1
2. Attached CD × 1
3. User manual × 1
4. Certificate of quality × 1
5. Warranty card × 1

6.DIN-Rail fittings  × 1

IES7120G-4GS:    16 ports 10/100/1000Base-T(X) + 4 gigabit fiber ports(SFP slots), 12~48VDC, DIN-rail mounted
