24 ports Industrial Ethernet Switch

    ES1024 support 24 port 10Base-T/100BaseTX ; no fan, low consumption, industry 4 grade design, can adapt rugged industry environment; 0~70℃ working temperature can satisfy some requirements of industry filed, can provide economical solution for your Ethernet connection.

1. Support IEEE802.3/802.3u/802.3x
2. Support auto-consult function
3. Support MDI/MDI-X self-adaption
4. Support 8K MAC address table
5. 0-70℃ working temperature
6. No fan, low consumption
7. IP40 protection class
8. 1U 19 inch rack mount

Switch

Properties

Forward speed: 148810pps

Maximum filter speed: 148810pps
Transmit mode: store and forward
Backplane bandwidth: 12.8Gbps
MAC table size: 8K
Buffer size: 4M

Electrical Port: RJ45 Connector, 10/100Base-T(X) auto negotiation , Half/full duplex and MDI/MDI-X auto detect

10/100Base-T(X):CAT5/CAT5e UTP(≤100m)

Input voltage: 100-240VAC/DC
Input type: 4 bits terminal block
No-load consumption: 4.2W
Full-load consumption: 6.7W

Shell: IP30 protect grade, metal shell
Size(W×H×D): 441.6mm×208.9mm×44.6mm

Installation: 19” 1U rack mounted

EMI: FCC Part 15, CISPR (EN55022) class A
EMS:  EN61000-4-2 (ESD), Level 4
EN61000-4-4 (EFT) , Level 4
EN61000-4-5 (Surge) , Level 4
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Shake: IEC 60068-2-6
