24 ports Managed Industrial Ethernet Fiber Switch

FOB Price

USD $1 - $2,000 / Piece

1 Piece(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	3onedata/OEM
Model Number	IES5024-20F

Product Description

24 ports Managed Industrial Ethernet Fiber Switch

Introduction

IES5024-20F is an industrial grade, managed and redundancy Ethernet switch which supports 4 Electrical Ports and 20 Fiber ports. It provides some kinds of advanced network managed function, such as: SW-Ring redundancy ring network, VLAN, Trunking, Quality of Service, Flow control, port mirroring, fault alarm and firmware upgrade online. SW-Ring can bring your Ethernet network to intelligent redundancy. Standard industrial design, can satisfied every requirement of the industrial scene. All components are industrial grade, make the switch high reliability.
Switch complies with FCC and CE standards, in line with the industrial design requirements, for industrial Ethernet application provides high-performance, high-quality products guaranteed. Support 1 channel power input and 1 channel relay alarm output, wide voltage range of power supply input,wide temperature range of -40~75℃ to be able to meet the requirements of all kinds of industrial field, can be widely used in electric power, water conservancy, transportation, and other fields.

Features

1.Support IEEE802.3, IEEE802.3u, IEEE 802.3x, IEEE802.1Q, IEEE802.1p, IEEE802.1D, IEEE802.1W
2.SW-Ring ring network patent technology (Fault recovery time<20ms)
3.Support RSTP, Convergence time<50ms
4.Support static multicast, IGMP Snooping and GMRP
5.Support Port based VLAN and IEEE 802.1Q VLAN
6.Support QOS absolutely and opposite priority
7.Support flow control, Broadcast storm control
8.Support WEB, SNMP and Telnet configuration
9.Support MAC address learning, aging automatic
10.Support DHCP server and port frame statistics
11.Support email warning and relay warning
12.Support port status display, data update.
13.Support configuration file upload and download
14.Support 1 channel relay alarm output
15.Industrial grade 4 design, -40-75℃working temperature
16.IP30 protection grade, rugged high-strength metal case

17.No fan design

18.19-inch rack mounted

Specification
Standard	IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.1Q, IEEE802.1p, IEEE802.1D, IEEE802.1W
Protocol	ARP, ICMP, TCP, DHCP, DNS, HTTP, Telnet, SW-Ring, RSTP, SNMP
Flow Control	IEEE802.3x flow control, Back pressure flow control
Switch Function	SW-Ring, QOS, 802.1QVLAN, RSTP, SNMP, Port trunking, static multicast filter, port mirroring, bandwidth management, broadcast storm control, port flow statistics, upgrade online, up and download configuration file, user name access system
Switch Properties	Forward speed: 148810pps Maximum filter speed: 148810pps Transmit mode: store and forward Backplane bandwidth: 12.8Gbps MAC table size: 8K Buffer size: 4M
Interface	Electrical Port: RJ45 Connector, 10/100Base-T(X) auto negotiation , Half/full duplex and MDI/MDI-X auto detect Optical Fiber Port: 100Base-FX, SC/ST/FC connector Console port: RS-232(RJ45 Connector) debug serial port Alarm port: 1 channel relay alarm output( 2 bit terminal block) Power port: 1 channel power iutput( 3 bit terminal block)
Transfer Medium	10/100Base-T(X):CAT5/CAT5e UTP(≤100m) 100Base-FX:Optical Fiber Multi-mode: 1310nm, 2Km Single-mode: 1310nm, 20/40/60Km 1550nm, 80/100/120Km wavelength: 1310nm, 1550nm
Indicator	Run indicator: Run Interface indicator: Link (1~24) Power supply indicator: PWR Alarm indicator: Alarm
Power Supply	Input Voltage: 100~240VAC Connector: 3 bits terminal block Overload current protect: 1.2A
Consumption	No-load consumption: 19.4W Full-load consumption: 20.9W
Environment Requirement	Working temperature: -40~75℃ Storage temperature: -40~85℃ Relative Humidity: 5%~95 %( no condensation)
Physical Characterisitics	Shell: IP30 protect grade, metal shell Size(W×H×D): 441.6mm×45mm×208.9mm Weight:2.82kg Installation: 19” 1U rack mounted
Industrial Standard	EMI: FCC Part 15, CISPR (EN55022) class A EMS: EN61000-4-2 (ESD), Leve 4 EN61000-4-3 (RS), Level 3 EN61000-4-4 (EFT), Level 4 EN61000-4-5 (Surge), Level 4 EN61000-4-6 (CS), Level 3 EN61000-4-8, Level 5 Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Vibration: IEC 60068-2-6
Certification	CE, FCC, RoHS, UL508 (Pending)
Warranty	5 years
Packing List	1. Industrial Ethernet Switch IES5024-20F (plus terminal block) × 1 2. Attached CD × 1 3. User manual × 1 4. Certificate of quality × 1 5. Warranty card × 1 6. Power cable × 1

Dimension

Show Case

Package

Shipping

Order Information

IES5024-20F (M): 4 port 10/100Baes-T(X) + 20 port 100Base-FX Multi-mode SC/ST/FC, 100-240VAC

IES5024-20F (S): 4 port 10/100Baes-T(X) + 20 port 100Base-FX Single-mode SC/ST/FC, 100-240VAC

IES5024-20F (SS): 4 port 10/100Baes-T(X) + 20 port 100Base-FX single-mode, single fiber SC/ST/FC, 100-240VAC
