Rotary Tablet Press Machine ZP-9 Series
- 0 per Month
- SHANGHAI
- Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | Minhua | |
| Model Number | ZP-9 Series | Type | Other, Tablet Pressing Machine |
Product Description
Specifications
This machine is a continuous automatic production tablet press,can be used to press tablets of 4-12mm in all shape.
Instructions & Scope
1. This machine is a continuous automatic production tablet press for checking whether granular raw materials can be pressed into tablets. It is mainly used in pharmaceutical industry as well as the chemical, food, electronic industries.
2. This machine is fit for pressing granular raw materials which can be pressed into tablets (within its pressure range) and whose powder content used to palletize should not be beyond 10% (≥100 mest).
3. This machine can be used to press tablets of 412 mm in original or special shape, or with lettering.
4. This machine is not adapted to palletize semisolid, low melting point, easily humidification granule and powder materials.
. Main Technical Parameters
No. | Name | Unit | Index |
1 | Quantity of Punch Die on Revolving Table | set | 9 |
2 | Max. Working Pressure | KN | 40 |
3 | Max. Diameter of Tablet | mm | 12 |
4 | Max. Thickness of Tablet | mm | 6 |
5 | Max. Depth of Fill | mm | 15 |
6 | Max. Production Capacity | tablets/hour | 17280 |
7 | Rotational Diameter | mm | 130 |
8 | Turret Speed | r/min | 032 |
9 | Diameter of the Die | mm | 26 |
10 | Height of the Die | mm | 22 |
11 | Diameter of up/down Punch Pole | mm | 22 |
12 | Length of up/down Punch Pole | mm | 115 |
13 | Dimension(L×W×H) | mm | 480×480×950 |
14 | Weight | kg | 180 |
15 | Motor Power | kw | 1.1 |
16 | Voltage | v | 220 |
