DP 30,40 Single Punch Tablet Press

This machine can press round or irregular tablets from various granulator materials.

This machine is applicable to trial manufacture,or batch produce in small scale in lab,hospital,

or science research departments.

Features:

1. Glossy finished stainless steel belt cover,meet the GMP request

2. Output is adjusted by frequency converter

3. High precision of filling

4. Operating reliably,low noise

5. Lower consumption of material,the minimum consumption of lab material is just 200g

6. Free with a pair of punch and die,spare parts free of charge for a year.

Technical data:

                     Model                                                DP30A                    DP40A

                     Dies                                                    1 set                        1 set

                     Max.diameter of tablet                         20 mm                    30 mm

                     Max. pressure                                     30 KN                     40 KN

                     Max. depth of fill                                 20 mm                    22 mm

                     Max. output                                    3600 tablet/hour      3600 tablet/hour

                     Power supply                                  AC,220V/50HZ        AC,220V/50HZ

                     Power                                                 0.55 KW                0.75 KW

                     Weight                                                150 kg                   200 kg

                     Overall size                                    708*459*740 mm     850*550*890 mm
