Semiautomatic filling and packaging machine DCS-1B-1
- shanghai
You May Like
Product Details
| Condition | New | Application | Other, Machinery & Hardware | |
| Packaging Material | Plastic | Automatic Grade | Semi-Automatic | |
| Driven Type | Electric | Place of Origin | Shanghai, China | |
| Brand Name | Minhua, Minhua | Model Number | DSC, DCS-1B |
Product Description
Specifications
DCS-1B-1 Semiautomatic filling and packaging machineDescription
This type can do measuring and filling work. Due to the special design, so it fits more to the fluidic or low-fluidity materials, like milk powder, gourmet powder ,solid drink, white sugar, dextrose, coffee, fodder , solid medicine, agriculture pesticide, granularity additive, dyestuff, and so on.
Features
Dexterous and flexible, easy removal. There is no limit of packaged container. It is widely used invariable materials and package-weight specifications.
High speed response(exclusive in china) on-off or servo motor drive screw .High precision, high speed, big torsional moment, long life to use.
weight feedback to run after the specific weight, overcome the shortcoming of the net weight change with the material specific-weight.
LCD or LED , simply visual supervisory. Stepless adjust the net weight. Change the working parameter at any time, easy to control. Change the working parameter at any time, easy to control.
Save the parameter of each product to later use. 10 sets of magistral fomula save at the most.
Fit for lots of material range from fine-powder to coarse-granule, if change the screw attachment. Dust- collector set on dust material situation to absorb dust spout out.
Technical parameters
Main Specification | |
Metering Mode | screw rotation filling traced by weighing feedback |
package weight | 110 5000g (The screw attachment is to be changed) |
weighing range | package weight ≤ 100g, with an error≤±2% |
| 100 500g,with an error≤±1% |
| 500g,with an error≤±0.5% |
packaging rate | 10 45bags/min |
power supply | three-phase 380V 50 60Hz |
Total power | 1.5KW |
Total Weight | 260Kg |
Overall Dimensions | 1140×970×2030mm |
Hopper Volume | 45L(70 liter for oversized hopper) |
