Home > Products > HIMA > HIMA F3313 Digital Output Module

HIMA F3313 Digital Output Module

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T PayPal Western Union

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other	Certification	Other
Function	Other	Condition	Other
Task	Other	Mathematical Model	Other
Signal	Other	Customized	Other
Structure	Other

Product Description

HIMA F3313 Digital Output Module

Functional Features

Safety-level Digital Output
It can receive control commands from safety controllers and output digital signals (such as switching signals) that meet safety standards. These signals are used to drive external actuators, such as safety valves, emergency stop devices, contactors, solenoid valves, etc., so as to realize safe start-stop and interlock control of equipment.
High Safety and Reliability
It complies with international safety standards (such as SIL 3, TüV certification, etc.) and is equipped with fault detection and diagnosis functions. It can monitor abnormal states such as short circuits and open circuits of output channels, ensuring that no misoperation occurs in case of faults and guaranteeing the safe operation of industrial systems.
Isolation Protection
It adopts internal optoelectronic isolation or electromagnetic isolation design to isolate the internal circuit of the module from external executive equipment. This avoids external electrical interference (such as surges, noise) affecting the module and control system, and also prevents external faults from spreading to the internal circuit.
Status Indication and Diagnosis
It is equipped with LED indicators, which can intuitively display the working status of each output channel (such as normal output, fault, overload, etc.). This facilitates engineers to quickly troubleshoot problems and improves maintenance efficiency.
Compatibility
It is compatible with HIMA series safety controllers (such as HIMax, H41q, etc.) and other control systems that meet industrial standards. It supports mainstream fieldbus protocols (such as Interbus, PROFIBUS, etc.), facilitating system integration and expansion.

Technical Parameters (Refer to Typical Specifications)

Number of Output Channels: Usually 8 channels or 16 channels (subject to the specific model), supporting independent control.
Output Signal Type: DC switching output, commonly 24V DC. The drivable load current range is generally 0.5A~2A (per channel).
Power Supply Requirements: Usually powered by 24V DC, with overvoltage and overcurrent protection functions.
Safety Level: Complies with safety standards such as SIL 3 (IEC 61508) and EN 50155.
Installation Method: DIN rail mounting, suitable for dense layout in industrial control cabinets, with convenient installation and replacement.
Environmental Adaptability: The operating temperature range is generally -20℃~60℃. It has certain anti-vibration and anti-impact capabilities, adapting to harsh industrial on-site environments.

Typical Application Scenarios

Chemical and Petrochemical Industry
In the safety control systems of chemical reactors and storage tank areas, it is used to drive emergency shut-off valves, safety interlock valves, etc. When the system detects dangerous signals such as excessive pressure and leakage, the F3313 module can quickly output signals to close the valves and prevent the spread of danger.
Oil and Gas Extraction and Transportation
In the Safety Instrumented System (SIS) of oil and gas pipelines and drilling platforms, it controls emergency shutdown devices and fire and explosion-proof equipment (such as shut-off valves linked with flame detectors). This ensures that the source of danger is quickly cut off in case of accidents such as leakage and fire.
Power Industry
In the safety control systems of power plants and substations, it is used to drive emergency isolation devices of generators and transformers, cooling system valves, etc. When abnormal conditions such as overvoltage and overcurrent are detected, it can trigger protection actions in time to avoid equipment damage or large-area power outages.
Industrial Automation Production Lines
In production lines of industries such as automobile manufacturing, metallurgy, and mechanical processing, it controls safety door interlocks, emergency stop button linkage devices, etc. When operators accidentally enter dangerous areas or trigger emergency stop signals, the module can immediately cut off the equipment power to prevent personal injury.
Municipal and Environmental Protection Fields
In water treatment plants and sewage treatment systems, it controls the safe start-stop of equipment such as water pumps and gates. When excessive water quality or equipment failures are detected, it shuts down relevant equipment through output signals from the module, ensuring the stable operation of the treatment system.

Working Principle

Receiving Control Commands: The module is connected to the safety controller through a communication interface and receives logical control commands from the controller (such as "output high level" or "output low level").
Signal Processing and Isolation: After the commands are processed by the internal circuit, they are transmitted to the output drive circuit through isolation components (such as optocouplers) to ensure electrical isolation between internal signals and external executive equipment.
Driving External Equipment: The output circuit outputs corresponding electrical signals (such as 24V DC) according to the commands to drive external actuators to act (such as valve closing, motor shutdown).
Status Feedback and Diagnosis: The module monitors the voltage and current status of the output channels in real time, feeds back fault information (such as short circuits, overloads) to the controller, and displays it through LED indicators, facilitating system monitoring and maintenance.

With high safety, reliability, and compatibility, the HIMA F3313 module has become a key component for realizing safe output control in industrial safety control systems. It is widely used in fields with strict safety level requirements, providing guarantees for the stable operation of industrial processes.
