Home > Products > Bently Nevada > BENTLY 3500/22M 138607-01 Transient Data Interface Module

BENTLY 3500/22M 138607-01 Transient Data Interface Module

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T PayPal Western Union

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other, Global universal model	Condition	Other, Global universal model
Task	Other, Global universal model	Mathematical Model	Other, Global universal model
Signal	Other, Global universal model	Customized	Non-Customized
Structure	Other, Global universal model	Operating temperature	-40℃~+85℃
Humidity	5%~95% (non-condensing)

Product Description

Many products are not on the shelves yet, please contact us for more models.

Bently Nevada 3500/22M 138607-01 is a Transient Data Interface (TDI) module designed to collect and process transient vibration signals, then transmit them to upper-level computers for analysis and diagnosis. Below is the relevant content from its user manual:

Product Features

High-Speed Acquisition: Capable of collecting transient vibration signals at a high sampling rate.
High-Precision Processing: Provides accurate calculation and analysis of vibration parameters.
Strong Compatibility: Compatible with other modules and software in the 3500 series.
Easy Maintenance: Modular design facilitates installation and maintenance.

Technical Parameters

Power Supply: Input voltage of 24V DC.
Signal Output: Output voltage 0 to 5V DC, output current 10mA.
Number of Channels: 8 channels.
Sampling Rate: 10kHz.
Resolution and Accuracy: 12-bit resolution, accuracy of ±0.1%.
Data Communication: Interface type is Ethernet; communication protocol is Bently Nevada proprietary protocol; data rate is 100Mbps.

Operating Environment:

Operating temperature: 0°C to 55°C.
Storage temperature: -40°C to 70°C.
Relative humidity: 5% to 95% (non-condensing).

Dimensions and Weight: Approximately 75mm x 178mm x 25mm in size; weight 0.3kg.
Installation Instructions
The TDI module is installed in the slot adjacent to the power supply in the 3500 rack, typically occupying slot 1.
Meanings of Front Panel Indicators
Normal LED: Indicates when the 3500/22M is operating normally.
TX/RX LED: Indicates when the 3500/22M is communicating with other modules in the rack.
TM LED: Indicates when the 3500 rack is in Trip Multiplier mode.
Configuration Normal LED: Indicates that the 3500 frame has a valid configuration.
Data Collection Functions
Keyphasor Input: Supports four keyphasor signals of the 3500 system and multiple rotation speed inputs up to 20kHz.
Startup/Deceleration Data: Collects data at preset speed and time intervals; acceleration and deceleration intervals can be programmed separately, and transient data collection starts when machine speed is detected.
Alarm Data Collection: Collects 2.5 minutes of waveform data every 10 seconds before an alarm, and 1 minute of waveform data every 10 seconds after an alarm; also collects static value data at different time intervals before and after an event.
