High-capacity Crusher With Extremely Strong Crushing Force

The Quad-Shaft Shredder (also known as a Four-Shaft Shredder) is a heavy-duty industrial shredding machine designed for high-capacity, high-torque processing of complex and tough materials. With four interlocking shafts equipped with hardened cutting blades, it delivers superior shredding efficiency for metals, tires, electronic waste (WEEE), industrial scrap, and bulky municipal solid waste (MSW).

? Four-Shaft Cutting System – Enhanced shearing, tearing, and crushing for maximum material breakdown.
? Extreme Durability – Built for 24/7 operation in demanding recycling and waste processing plants.
? Smart Automation – PLC-controlled with overload protection, auto-reverse, and real-time monitoring.
? Wide Material Adaptability – Handles mixed waste streams with high metal/elastic content.

• Four counter-rotating shafts with intermeshing blades for multi-stage shredding.

• Low-speed, high-torque (up to 200 kN·m) for hard-to-shred materials (e.g., steel, aluminum, tires).

• Adjustable output size (15–150mm) via changeable screen meshes.

• Reinforced steel frame for long-term stability.

• Modular blade design:

• Base material: High-chromium alloy steel.

• Cutting edges: Tungsten carbide or hard-faced welding for extended wear resistance.

• Fully automated PLC control with:

• Auto-reverse function (anti-jamming).

• Hydraulic pusher system (optional, for continuous feeding).

• Energy-saving mode (reduces power consumption during low-load operation).

• CE/ISO-certified safety features:

• Emergency stop buttons.

• Safety interlocks on access doors.

• Noise & dust suppression:

• Closed-loop design (noise <80dB).

• Dust extraction ports (compatible with baghouse filters).
