7005 High Speed Cnc Lathe Spindle Bearing H7005C/ P4 DTA Hybrid Bearings 7005 HQ1 C DB P4
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
DAC3872 WHEEL BEARING KOYO DAC 3872 W-8CS81 Auto Wheel Bearing DAC3872-W-8CS81
-
5201Angular Contact Ball Bearing 5201-2RS
-
Germany Brand HCS7007C-T-P4S-DU L Sealed Hybrid Ceramic Bearing 7007 2rz Spindle Bearing 7007
-
H7007C 2RZ HQ1 P4 Sealed Hybrid Ceramic Bearing 7007 2rz Spindle Bearing 7007-2RS
-
F-809030.05 Angular Contact Ball Bearing F-809030.05 Air Compressor Bearing F-809030.05.KOMBI
-
3211BD Double Row Angular Contact Ball Bearing 3211-BD-XL-TVH 3211-BD-XL-TVH-C3
Product Description
Product Description
high speed cnc lathe spindle bearing H7005C/ P4 DTA hybrid bearings 7005 HQ1 C DB P4 Ceramic Ball Bearings
Structure-Ceramic Ball/Angular Contact ball
Model number- H7005C/ P4
Size :Inner ring(mm)-25 Outer ring(mm)-47Width(mm)-12 Weight(Kg)-0.093
Materials-Chrome steel/GCR15
Precision grade-P5/P4/P2
Lubrication type-Grease lubrication
Contact Angle-C=15°;AC=25°
Material(Ball)-SN24:Ceramic ball(Si3N4)
Number of Row-Single rows
Material(Cage)-TN /PN
Combination-
SU:Universal combination (single row)
DU:Universal combination (double rows)
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
Categories:Angular Contact Ball Bearings Ceramic Ball Bearings
Related Search:7005AC / CHQ1P4,7005C Ceramic Ball Bearings,7005C Spindle bearing,7005C High Speed Bearing
Product Features
Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision Spindle and Motors
Series Introduction
High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed
bearings-70 Series Angular Contact Bearings Series
Model No.
7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,
7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
Applications High Speed Ceramic Ball Angular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrialequipment
Product Features
Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision Spindle and Motors
Series Introduction
High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed
bearings-70 Series Angular Contact Bearings Series
Model No.
7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,
7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
Applications High Speed Ceramic Ball Angular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrialequipment
name | cnc lathe spindle bearing H7005C/ P4 |
ball material | Si3N4 |
ID | 25MM |
OD | 12MM |
B | 10MM |
Product weight | 0.093kg |
Cage Material: | TN |
material | chrome steel |
mail | sales1@landlionbearing.com |
Tel | +86-18710180456 |
Related Products
bearing | d | D | B | c | Da | da | contact angle | weight KG |
B7000-C-2RSD-T-P4S-UL | 10 | 26 | 8 | 6.4 | 22 | 14 | 15° | 0.02 |
B7001-C-2RSD-T-P4S-UL | 12 | 28 | 8 | 6.7 | 24.5 | 16.5 | 15° | 0.02 |
B7002-C-2RSD-T-P4S-UL | 15 | 32 | 9 | 7.6 | 28 | 19 | 15° | 0.03 |
B7003-C-2RSD-T-P4S-UL | 17 | 35 | 10 | 8.5 | 32 | 21 | 15° | 0.04 |
B7004-C-2RSD-T-P4S-UL | 20 | 42 | 12 | 10.2 | 37 | 25 | 15° | 0.07 |
B7005-C-2RSD-T-P4S-UL | 25 | 47 | 12 | 10.8 | 42 | 30 | 15° | 0.08 |
B7006-C-2RSD-T-P4S-UL | 30 | 55 | 13 | 12.3 | 49 | 36 | 15° | 0.11 |
B7007-C-2RSD-T-P4S-UL | 35 | 62 | 14 | 13.5 | 56 | 41 | 15° | 0.15 |
B7008-C-2RSD-T-P4S-UL | 40 | 68 | 15 | 14.7 | 62 | 46 | 15° | 0.19 |
B7009-C-2RSD-T-P4S-UL | 45 | 75 | 16 | 16 | 69 | 51 | 15° | 0.24 |
B7010-C-2RSD-T-P4S-UL | 50 | 80 | 16 | 16.7 | 74 | 56 | 15° | 0.25 |
B7011-C-2RSD-T-P4S-UL | 55 | 90 | 18 | 18.7 | 83 | 62 | 15° | 0.38 |
B7012-C-2RSD-T-P4S-UL | 60 | 95 | 18 | 19.4 | 88 | 67 | 15° | 0.4 |
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
