Product Description

Products Description

·The second emission is equipped with supercharged and Intercooled engine, which has large torque reserve and strong power
·The new cooling system is designed to meet the working requirements of ambient temperature from - 40 °C to 50 °C above zero
·International advanced technology transmission, electro-hydraulic control power shift, front six and three gears
·Three stage drive rear axle, equipped with no ~ spin differential, reliable and durable
·The spacious and comfortable cab is located on the front frame, with clear vision and easy operation. It can also be equipped
with ROPS
·Imported Rexroth variable piston pump is equipped as standard, which can distribute flow according to demand and save energy
consumption

·Cater-pillar's unique proportional priority and pressure compensation control valve (pppc) make the machine control more
sensitive and improve the overall performance and efficiency of the machine
·The blade control system and application range of the electro-hydraulic and world-class grader control the traction frame
positioning pin and seven hole connecting rod to quickly obtain the most extensive blade positioning
·The optimized blade radian and larger throat clearance material have good trafficability and fluidity, and improve production
efficiency
·Unique front axle design, industry-leading tire tilt angle and steering angle, maximize the operability of the machine
·A variety of working tools can be selected to meet the needs of customers in different working conditions

Specification

Model		921
Item	Unit	Parameters
Operation Weight (Base Machine)	kg	15930
Overall Dimensions (LWH)	mm	8,8542,6303,360
Blade Length (LWH)	mm	4,27925607
Max. Lifting Height	mm	475
Max. Depth of Cut	mm	715
Max. Drawbar	kN	≥85
Wheelbase	mm	6140
Frame Articulation Angle	°	20
Min. Turning Radius	m	7.8
Engine Brand		SDEC SC9DK220G3
Rated power	kW	162
Transmission Type		Hangchi 6WG180
Travel Speed (Forward/Rear)	km/h	40/25
Rear Axle/Tandem		ST22
Service brake		Outboard disc with brake caliper,Air to oil Control
Oscillation (Front up/Rear up)	°	15/25
Max. Oscillation Angle	°	±16
Steering Angle (Left/Right)	°	47.5
Max. Lean Angle of Front Wheels	°	18
Hydraulic System		Load sensing,PPPC
Service Refill Capacity
Fuel Tank	L	320
Engine Oil	L	22
Coolant	L	65
Transmission	L	28
Rear Axle (Main Reducer & Tandem)	L	157
Circle Drive (Standard)	L	2
Circle Drive (with Slip Clutch)	L	7
Hydraulic Oil Tank	L	55
