Product Description
Products Description
4.5M Wheeled Type Asphalt Paver RP453L
RP453L paver with full hydraulic four-wheel drive, continuously variable, equipped with SC4H100G3 water-cooled turbocharged diesel engine, power up to 73.5KW, gas heated hydraulic telescoping screed, steplessly adjustable vibration frequency, paving width from 2 meters to 4.5 meters width.
The functional console is modularized, the control system of the main switchgear is used, the automatic leveling
device is used, the transverse gradient is within 0.02%, wet multi-disc brakes are used for driving and Parking brake, the whole machine is safe and reliable, and the material-discharging blades are made of highly wear-resistant Cr-Ni-based materials to extend the service life.
Specification
Description | Unit | Parameter value |
Dimension | mm | 5690*2070*3590 |
Weight | kg | 11000 |
Driving speed | m/min | 0-20 |
Basic pave width | m | 1.8-3.4 |
Maximum pave width | m | 4.5 |
Maximum layer thickness | mm | 260 |
Maximum paving speed | m/min | 18 |
Hopper capacity | kg | 12000 |
Maximum laydown rate | t/h | 240 |
Rate power | kw/rpm | 73.5/2000 |
Details Images
