JET air-blown micro- optic cable for backbone network, access network and fibre optic cable to the home,Air Blowing Duct cable

Loose tube non-metallic air-blown micro-optic cable (JET)

Product Description

The structure of miniature JET is put 250µm single-mode or multi-mode optical fiber into a loose tube,the loose tube is made of high modulus material, which are filled with non-toxic and harmless waterproof compounds. Outside of loose tube is stranded with non-metallic reinforced element aramid, then extruded black or colored high-density polyethylene (HDPE) sheath form a cable.

 Product Characteristics

• Non - metallic structure design effectively prevent radio - frequency interference and electromagnetic interference

•  Specially designed compact cable structure to effectively prevent the tube from retracting

•  Aramid reinforcing element makes the cable have excellent tensile properties

•  The loose tube is filled with special grease, which fully guarantees the waterproof performance of the optical cable

•  With good softness

•  High dense fiber packed, small diameter and light weight, it  is the best option for blowing

 Optical Fibre Performance

 Technical Performance

Environmental Characteristics

• Transport/storage temperature: -30℃ to +70℃

Application

• Especially suitable for backbone network, access network and optical fiber to the home
