Low Toxicity 4mm2 PV Solar DC Cable for Photovoltaic System
- Shenzhen
- T/T Credit Card
You May Like
-
High Voltage Single Core PV Solar Electric Cable 4mm2 for Solar Project
-
China Supply XLPE XLPO Double Insulation Cooper Wire DC Solar PV Cable 2.5mm
-
2x2.5mm2 Dual-Core Solar PV Cable in SUPERSEPTEMBER Activity
-
6mm Solar Cable Belongs To Discounted PV Products
-
Slocable Electron Beam Cross Linked UV Resistance 2.5mm 2 PfG 1169 Solar Cable
-
Slocable Big PV System Project 4mm Solar PV Cable
Product Details
| Brand Name | Slocable | Place of Origin | Guangdong, China | |
| Model Number | CA104B-PE solar cable | Type | High Voltage | |
| Conductor Material | Copper |
Product Description
Low Toxicity 4mm2 PV Solar DC Cable for Photovoltaic System
Product Description
| Size | Cross Section | Conductor Structure | Outer Diameter |
Max. DC Resistance at 20℃ | Rated Voltage | Rated Current |
| mm² | mm | mm | Ω/km | V DC | A | |
| 1 x 2.5mm² | 2.5mm² | 49 x ∅0.25 | 5.4 | 8.06 | 1000/1500 | 30A |
| 1 x 4.0mm² | 4.0mm² | 56 x ∅0.285 | 6.1 | 4.97 | 1000/1500 | 50A |
| 1 x 6.0mm² | 6.0mm² | 78 x ∅0.30 | 6.4 | 3.52 | 1000/1500 | 70A |
| 1 x 10.0mm² | 10.0mm² | 74 x ∅0.40 | 7.3 | 2.12 | 1000/1500 | 95A |
Technical Data
Conductor: 99.7% copper, tinned | UV resistance |
| Insulation material: XLPE(XLPO) | High voltage and High current |
| Double walls insulation | Temperature range: -40°C ~ +85°C |
| Halogen-free material | Color: Black/Red/Blue |
| Flame test according to: DIN EN 50265-2-1 UL 1571(VW-1) | Smallest permissible bending radius: 5 x D |
Advantages of Product
- Dual wall insulation,Electron beam cross-linked.
- Resistance to UV,water,ozone,fluids,salt,general weathering.
- Halogen free,flame,retardant,low toxicity.
- Flexibility and stripping performance.
- TUV approved.
- High current carrying capacity.
- Resistance to abrasion.
Frequently Asked Question
Q1: What is your company's Main Products ? You are the Manufacturer or the trader ?
Solar Cables, Solar Connectors, PV Fuse Holder,Circuit breakers and other solar relative products.We're the Manufacturer with more than 11 years experience.
1) All raw material we selected the high quality one.
2) Professional & Skilful workers care every details in handling the producing.
3) Quality Control Department specially responsible for quality checking in each process.
Q4: Do you provide OEM Project Service?
OEM & ODM order is warmly welcome and we have fully successful experience in OEM projects.
What's more, our R&D team will give you the professional suggestions.
Q5: How Could I get the Sample?
We are honored to offer you samples,Samples is free provided,but need pay the courier freight.
If you have a courier account, you can send your courier to collect samples.
Q6: How long is the Delivery Time?
1) For Sample: 1-3 Days ;
2) For small Orders: 3-10 Days;
3) For mass Orders: 10-18 Days.
