2.92 & 2.4 & 3.5 Male Connector High frequency test cable,Direct Solder for .047 Cable, tested to 40 GHz
- shenzhen
- T/T
- 3 days
You May Like
-
IPEX/MHF 20278-112R-13
-
TNC male- SMB female right angle coxial cable
-
High performance odm 2.4GHz N male connector antenna manufacturer,connector for flexible cable
-
high gain outdoor Mushroom Marine Gps glonass Antenna with TNC female connector
-
Fakra N Male Pastel Green Crimp Solder Connector for Car GPS Antenna RG316 RG174 Cable SHM.900.0009-1.N
-
RF Fakra Z Water Blue Male End Launch PCB Mount with Solder Terminal Connector SHM.900.0004-3.Z
Product Description
2.92 & 2.4 & 3.5 Male Connector High frequency test cable,Direct Solder for .047 Cable, tested to 40 GHz
When you send the RFQ for RF coaxial cable assemblies, please have below information included in your inquiry: Types of the connectors for both ends, that you can choose the Low Loss SMA Cable Assembly from our websites Type of coaxial cable, you can choose flexi
2.4mm high frequency male connector Electrical parameters | |
Impedance | 50 Ohm |
Frequency range | DC~40GHz |
Voltage rating | 250 V(rms) |
Dielectric withstanding voltage | >750V |
Center contact resistance | <3.0mΩ |
Outer contact resistance | <2.0mΩ |
Insulation resistance | >5000MΩ |
Insertion loss | <.05 sqrt(f(GHz)) dB |
VSWR | <1.20 |
High Frequency Test Cable Mechanical parameters | |
Center contact retention force | >20 N |
Coupling test torque | 1.65 Nm |
Recommended torque | 0.8 Nm to 1.10 Nm |
Durability | >500 cycles |
RF coaxial cable assemblies Environmental parameters | |
Temperature range | -65 ℃~+165 ℃ |
Thermal shock | MIL-STD-202, Meth. 107, Cond. B |
Corrosion | MIL-STD-202, Meth. 101, Cond. B |
Vibration | MIL-STD-202, Meth. 204, Cond. D |
Shock | MIL-STD-202, Meth. 213, Cond. I |
Interface | |
According to | IEC 61169-35 |
