Voltage Regulating Type Auto Var Compensator DTW
- Tianjin
- T/T L/C Credit Card PayPal
- 7 days
You May Like
-
SVC High Voltage Static Var Compensator Device For Reactive Power Compensation
-
Ruitong High Quality High-voltage Static Var Generator For Reactive Power Compensation
-
Ruitong APF Active Power Filter For Power Harmonic Control System
-
High-voltage Line Var Compensator GXW
-
Ruitong Low-voltage Static Var Generator For Reactive power Compensation
-
Low Voltage Var Compensation Controller For Reactive Power Compensation System
Product Details
| Brand Name | Ruitong | Place of Origin | China | |
| Model Number | RT-W-DTW |
Product Description
Product Overview: The RT-DTW voltage regulating type auto var compensator changes the reactive power inserted to the power grid by the capacitor bank by changing the reactive power of the capacitor bank into the power grid when the capacitor bank is fixedly input for fine reactive compensation. The device can be widely used not only for new substation establishment, but also for the upgrading of existing substations, of which the TBB compensators can be upgraded to the automatic var compensators with the 9-level compensation function. |
-- Voltage level: 6kV, 10kV, 35kV; -- Rated capacity: 630kvar - 6000kvar (6kV), 630kvar - 12500kvar (10kV), 1000kvar -- 36000kvar (35kV); -- Compensation level: 9; 18; -- Reactive power adjustment range: 36% to 100%; 25% to 100%; -- Control system: DSP full digital control system; -- Control method: fully automatic; -- Installation method: indoor, outdoor, box type substation.
|
