Single Axis Copy Router Door Hanger Hole Mill for Aluminum
- T/T Credit Card
You May Like
-
China Cnc Universal Milling Machine for Aluminium Window Dooor and Curtain Wall
-
3 Tool High Precision Drilling and Mini Cnc Milling Machine With Tool Changer for Aluminum Profiles Window and Doort
-
Aluminum Window Small Milling Hole Machine Copy Router
-
Aluminum Profile CNC Copy Routing Machine
-
Corner Crimping Aluminum Window Door Fabrication Machine
-
Aluminum Door Crimping for Sale Aluminium Window Machine
Product Details
| Brand Name | FEIDA |
Product Description
| Name | Single Axis copy router door hanger hole mill for aluminum |
| Model | FX-DW260D |
| Fuction | It is processing water slots, holes, groove of aluminum window&door. |
| Max. Copy Router | 290*90mm |
| Tool | Φ5,Φ8 |
| Power | 1.1KW |
| Voltage | 380V/50Hz |
| weight | 150kg |
| size | 800*1500*800mm |
--For copying sorts of figures and holes on aluminum profiles with processable wall thickness 1.5~3 mm.
--The copying templates and auxiliary ruler are adopted as two mechanical ways of copying performance.
--Automatic clamping and spray-cooling.
--Professional milling cutters are used for better performance
Main Specification door hanger hole mill for aluminum
1) Copying range (width x length): 90x260 mm
2) Cutter diameter : φ5mm, φ8mm
3) Rotational speed of cutter: 11200 r/min.
4) Machine power: 1.1 KW
5) Power supply: 380V, 50Hz, 3 phases, 4 wires
6) Pneumatic working pressure: 0.4 – 0.8 MPa
7) Air consumption: 0.1 m³ /min
8) Outer dimensions: 800x800x1500mm
9) Weight: 150 Kg
End Milling Precision door hanger hole mill for aluminum
1) Smooth finish of milling surface: Ra 12.5 µm
2) Copying tolerance in dimension: ± 0.1 mm
3) Copying tolerance on position: ± 0.1 mm
| Size | 800(L) × 1500 (W) × 800(H) |
| Weight | 150KGS |
| Packing details | Aluminum foil vacuumed /door hanger hole mill for aluminum |
