MANUFACTURER Manual Single Head Aluminium Profile Cutting Machine
- T/T Credit Card
You May Like
-
Cnc 22.54590 Degree Saw Small Aluminum Extrusion Machine for Window Door Profiles
-
Aluminum Billet Cutting Machine Aluminum Processing Machine
-
Manual Single Head Aluminum Window Making Machine Copy Router and Door
-
Drill Mill Hole 3 Axis Aluminum Profile Cnc Milling Machine
-
Aluminum Window Door Fabrication Machine Mini Metal Cnc Milling Machine
-
Aluminum Windows Manufacturing Tools Copy Router
Product Details
| Brand Name | FEIDA |
Product Description
Product Application manual single head aluminium profile cutting machine
--It is for aluminum alloy doors and windows, curtain wall profile single 45 degrees and 90 degrees of cutting.
--Gas-liquid damping cylinder to achieve uniform feed rate, stable operation.
--Saw blade feed system imported linear guide movement, high precision, good stability.
--Automatic landing gear to make work safe and convenient.
Main Specification manual single head aluminium profile cutting machine
1) Enter the power 380V 50Hz
2) input power 2.2Kw
3) Working pressure 0.5 ~ 0.8MPa
4) Air consumption 100L / min
5) Spindle speed 3200r / min
6) Sawing length 100 ~ 3500mm
7) Sawing width ≤130mm
8) Sawing height ≤300mm
9) Sawing angle 90 ° 45 °
10) Feed speed 0 ~ 3m / min
11) Blade specifications φ500 × 4.4 × φ30 × Z120
12) Dimensions 1600 × 1700 × 1600mm
Cutting Precision manual single head aluminium profile cutting machine
1) Repetition on length: ± 0.2mm
2) Repetition on angle: ± 5’
3) Verticality of cutting surface: 0.1mm (100x100mm section)
4) Planeness of cutting surface: 0.1mm (100x100mm section)
| Size | 1600(L) × 1700 (W) × 1600(H) |
| Weight | 350 KGS |
| Packing details | Aluminum foil vacuumed /manual single head aluminium profile cutting machine |
