XK7113 Machinery Machine Mini CNC Milling Machine for Hobby Use
US$ 1,500 - 2,000
/ Set
1 Set(Min. Order)
- mini cheap cnc milling machine delivered at Shanghai Port
- T/T Credit Card
You May Like
-
XK7113 Hobby CNC Milling Machine for Metal Working
-
XK7113 Small Metal Cnc Milling Machine for Sale
-
XK1860 4 Axis CNC Milling Machine With Tool Changer
-
XK7140 4 Axis Mini Metal CNC Milling Machine for Sale
-
XK7125 Mini CNC Milling Machine With Tool Changer
-
VMC850 CNC Milling Machine With Linear Guideway
Product Details
| Brand Name | WMT | Place of Origin | Anhui, China | |
| Condition | New |
Product Description
Product Description
Mini CNC milling machine XK7113
Main specification:
| Model | XK7113 |
| X-axis | 220mm |
| Y-axis | 120mm |
| Z-axis | 200mm |
| Drilling capacity | 13mm |
| T-slot | M12 |
| Table size | 400*140mm |
| Spindle speed | 0-3000rpm mach 3 control |
| Spindle motor | 3 phase DC type brushless motor with driver 550W |
| Spindle | ER20 no power spindle |
| Spindle center to column distance | 150mm |
| Spindle nose to table distance | 20mm |
| Screw | 1605 ball screw with double nuts to remove return difference |
| Guide way | 15 linear guideway,Double row ball slidees for each guideway |
| Step motor torque | X:2.5N.M Y:2.5N.M Z:3.5N.M |
| Machine size | 590*590*780mm |
| Machine weight | 84KG |
Features:
| Small size but high precision |
| DC brushless motor |
| Ballscrew |
| Liner guideway |
| Manual and automatic easy operation |
| Mach 3 controller, USB connection |
Standard accessories:
Mach 3 software for machine controlling
Machine stand
X/Y/Z linear guideway
ER20 spindle with stepper motor
ER chuck 2.4.6.8.10.12
Tool box with tools
Working video:
| https://youtu.be/MN8aqiGcp4M |
| https://youtu.be/qB1pi3JJ2OE |
