CK6140 horizontal cnc turning center with price
- Qingdao or Shanghai
- T/T Credit Card
You May Like
Product Details
| Brand Name | Lu Young | Place of Origin | Shandong, China | |
| Model Number | Ck6140 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New |
Product Description
CK6140 horizontal cnc turning center with price
Specification of CK6140 horizontal cnc turning center with price
| CK6140 horizontal cnc turning center with price | ||||
| Item | CK6140A | CK6140B | ||
| Max. swing dia. over bed | Φ400mm | Φ400mm | ||
| Max. swing dia. over cross slide | Φ225mm | Φ245mm | ||
| Max. processing length(mm) | 750 | 1000 | 750 | 1000 |
| Dia. of spindle hole | Φ60mm | Φ52mm | ||
| Spindle speed | 150-2500rpm | 150~500rpm (low) 320~1600rpm (high) | ||
| spindle taper | MT6 | |||
| Tool holder | 4 station electric tool post(optional 6/8staion electric turret) | |||
| Tool bar section | 20X20 | 20X20 | ||
| Main motor power | 5.5KW | 5.5KW | ||
| X/Z axis fast feeding speed | 6/8 M/MIN | 6/8 M/MIN | ||
| X/Z axis position accuracy(mm) | 0.01/0.015 | 0.01/0.015 | ||
| X/Z-axis repeatability(mm) | 0.012/0.013 | 0.012/0.013 | ||
| Clamping | 3 Jaw Manual Chuck(optional pnematic or hydraulic chuck) | |||
| Tailstock sleeve dia. | 60 | 60 | 60 | 60 |
| Tailstock sleeve travel | 120mm | 120mm | ||
| Tailstock taper | MT4 | |||
| Dimension | 2120X1400X1700 | 2050x1400x1650 | ||
| 2370X1400X1700 | 2300X1400X1650 | |||
| Weight(kg) | 1800 | 1950 | 1850 | 2050 |
| Standard configuration: | Optinal configuration: | |||
| GSK928 CNC Controller | Siemens,Fanuc cnc controller system | |||
| Servo motor for X,Z axis, Servo driven | pneumatic chuck,hydraulic chuck | |||
| 3 Jaw Manual Chuck | pneumatic tailstock,hydraulic tailstock | |||
| 4 station electric tool post | 6 staion tool turret,8staiton tool turret | |||
| Auto lubrication system | Auto feeder system | |||
| lighting system | Chip conveyor | |||
| cooling system | ||||
Oprional configuration of CK6140 horizontal cnc turning center with price
Product Feature of CK6140 horizontal cnc turning center with price
1.Processing complex and high precision workpiece. Bed head box optimization design,
suitable for discs, shaft parts of the turning process, you can line, arc, metric thread, long thread
processing, can be applied to the complex shape of the complex and high precision disk type,
shaft parts Processing.
2.High hardness, good rigidity, high audio quenching, machine guide rails and saddle rails are
using special materials, hard rail, high frequency quenching, super hard wear and tear, durable,
good processing accuracy
3.Automatic lubrication, the lubrication point of the use of forced automatic lubrication device for
quantitative quantitative lubrication of the screw and guide rail, when there is an abnormal state or
lack of fuel, the automatic warning signal.
4. High precision, low noise. Spindle high precision double ball bearing support, low noise, high
precision, good stability
5.Tailstock self-protection function, tailstock with fast cam clamping device, high efficiency.
Tailstock sleeve to prevent the drill bit rotation device, to avoid the malfunction caused by the drill
bit rotation and damage the tailstock sleeve hole taper, the effective protection of the tailstock parts.
6.Easy to operate, especially for complex parts or high-precision high-volume parts of the processing, but also the first choice of numerical control teaching.
Application of our cnc lathe machine:
Hot selling products:
CK0640 mini cnc lathe machine CK6432 cnc lathe machine CK6130 cnc lathe machine
CK6132 cnc lathe machine CK6136 cnc lathe machine CK6140 cnc lathe machine
Why choose our CK6140 horizontal cnc turning center with price ?
1.Products can be customized, meet all of your requirements.
2.20 years of production experience, technology improved unceasingly.
3.Competitive price, reject high profits. Make sure reduce your cost.
4. Rich export experience, to provide you with comprehensive and best services.
5.Use famous brand parts, high quality raw materials to ensure the quality of products.
6. 24×7 hours service.
20 years' production experience
The main product of Taian Luyoung Machinery Co.,Ltd is CNC lathe machine, CNC milling machine, CNC machine centers,CNC swiss type automatic lathe. Annual output is 900sets/ year.
1.More than 20 years of production experience.
2.Exported more than 40 countries.
3.More than 300 staffs in factory.
4.CE and ISO9001 certification .
5.7×24 hours online service.
The products have exported more than 40 countries around the world, please look who choose us:
Feedback from our customer:
7×24 hours after-sale service
1. Warranty for one year.
2.Supply 7×24 hours online technology support.
3.Professional solution one by one.
4.Free training for customers online or in our factory.
5.The oversea service is available.
Strong packing will protect the goods from any possible damage during transit
1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of collision and keep the goods intact.
FAQ:
1.How to get the best quotation?
| Tell me the model ,quantity and your requirements, then we will give you our best price to you. |
2.If we don’t know the model of the lathe,how to choose the model?
| Send the drawing of the workpiece ,then our technicist will recommend the exact model to you. |
3.How about the MOQ(Minimum Order Quantity)?
| 1 set |
1 set
4.Can we place an order by TRADE ASSURANCE?
| Of course, all of our orders can be placed by this way. Please rest assured your money. |
5.How long about your guarantee period?
| 12 months. If there are accessories damaged during the warranty period,we will we will replace it for free. |
6.How to contact you?
| My mobile/whatsapp: +86 18660853235; QQ:3494630853 |
