Home > Products > Wheel Repair Equipment > Rim Repair Machine WRM26H With Digital Optimization Software
Rim Repair Machine WRM26H With Digital Optimization Software
- T/T Credit Card

You May Like
-


WRM26H Alloy Wheel Repair Equipment
 -


WRM26H Alloy Wheel Lathe With ALL IN ONE Solution
 -


China Supplier Alloy Wheel Alloy Rim Repair CNC Lathe Cutting Repair Wheel Machine AWR2840
 -


AWR28H Alloy Wheel CNC Lathe Repair Machine For Sale
 -


Aluminum Wheel Repair Lathe WRM28H With Low Power Consumption
 -


WRM26H Hot Sale Rim Alloy Wheel Hub Pepair PC CNC Lathe Machine

Product Details
| Brand Name | Crystal | Place of Origin | Shandong, China | |
| Model Number | WRM26H | |||
| Year | 2018 | Condition | New |
Product Description
Rim repair machine WRM26H with digital optimization software
Our purpose build alloy wheel lathe incarcerates a user friendly multi-touch interface for simplified probing and cutting processes. With full digital optimization build directly into the interface, there is no need of a separated computer system to house the software, making this our best ALL IN ONE solution for repairing diamond cut alloy wheels.
Wheel Repair Lathe Advantages
1. Cuts wheel up to 27’’.
2. 17 inch interface touchscreen.
3. With CE, SGS, ISO, BV certificates.
4. Automatic ruby probe system.
5. Self-developed optimization software.
6. Free Training video and manual.
7. 7x24 hours technology support.
8. 2 USB interface.
9. High efficiency and economic.
10. Two-year warranty.
11. Free factory hand-to-hand training.
12. Agencies in UK, Germany, Poland, Netherlands, Australia etc.
Alloy Wheel Repair Lathe : Specifications
ITEMS  | WRM26H-PC  | |
Max. swig over bed (mm)(inch)  | Φ720(28’)  | |
Max. Diameter of alloy wheel(mm) (inch)  | Φ660(27’)  | |
Max. Stroke of the X-axis(mm)  | 350  | |
Max. Stroke of the Z-axis (mm)  | 850  | |
Width of the rail (mm)  | 330  | |
Length of the rail (mm)  | 1300  | |
Size of the three-jaw chuck (inch)  | 13’  | |
Range of spindle speed (RPM)  | 50-2000  | |
Spindle speed control  | Automatic  | |
Spindle bore (mm)  | Φ60  | |
Taper of spindle bore  | MT6  | |
Taper of spindle nose  | A2-8  | |
Adjustable stroke of carrier in X direction  | 100mm  | |
Max. size of tool post  | 25×25mm  | |
Stations of tool carrier  | 4 position  | |
Min. setting unit of motor  | (Z) long 0.001mm, (X) cross 0.001mm  | |
Moving speed of post  | (Z) long 8m/min, (X) cross 6m/min  | |
Motor power  | 7.5KW  | |
Machine size  | (L/W/H) (mm)  | 2200/1520/1840  |
Package size  |
  | 2300/1620/2140  |
Net weight  | 2200KGS  | |
Standard configuration:
| wireless key&mouse 1 set | diamond cutter 1 set inner |
| diamond cutter 1 set outer | special ordered soft jaws 1 set |
| high precision prob system 1 set | 4 station tool which can adjust X stroke |
| automatic lubrication system | cooling system(standard) |
| full cover safety door | tool case |
training videos  | -- |
Rim repair samples :


1.Q:The machine can repair wheel edge?
A:Yes, that’s no problem to repair wheel edge.
2.Q:The machine is easy to learn?
A:Yes, it is very easy to learn. The detailed manual and training video will be supplied
with machine together .
3.Q:Do I need any special software for my PC?
A:We will provide optimization software (It is specifically aimed at wheel repair and
we have independent intellectual property rights).
4.Q:What kind of tool that wheel repair machine use?
A: It is diamond cutting tools.
5.Q:How many time it takes to repair a wheel ?
A:For same model wheels, the first one needs about 10 minutes, because
probing wheel curve will take some time. After first one, the curve will be saved, so
when you repair other wheels as same model, it just takes about 3 minutes.
6.Q:Can we go to your factory and learn how to use the machine?
A:We sincerely welcome you come to our beautiful city. The training is free. It would
be great honor to us.
7.Q:Can you arrange training in our place after we bought your machine?
A:We can arrange oversea training. Buyers will be responsible to the costs.
Make you satisfied is our business!
1. The first batch of supplier joined Alibaba Trade Assurance.
Amount up to the top of Machinery Industry. Zero-risk Purchase service.
2. Over 400 clients from more than 80 countries could tell you we are your reliable
partner.
3. Professional in cnc machine.
Our price could beat any competitors in China market.
4. We supply professional solution based on your own process one by one.
5. Customer-made configurations available. Provide you more choices.
6. 7*24 hours before and after sale service.
7. 2 years guarantee for whole machine, 3 years warranty for CNC system, servo
motor, guide-rail.
