DL40x2000 Slant Bed Cnc Lathe Machine With CE
- Dalian China
- T/T Credit Card
You May Like
-
DL32Mx3000 Slant Bed Cnc Metal Lathe Machine
-
DL25/32MHYS Series Twin Spindle Cnc Turning Center for Sale
-
DL25MHSY Twin Spindle 4 Axis Slant Bed Cnc Turning Center for Sale
-
DL30MHSTY Double Spindle Cnc Turning Center With Live Tooling
-
DL-25/32MHYS Twin Spindle Cnc Turning Center for Sale
-
DL-MH(3 Axis) Series Slant Bed Cnc Turning Center
Product Details
| Brand Name | DALIAN | Place of Origin | Liaoning, China | |
| Model Number | DL40x2000 heavy duty slant bed cnc lathe machine | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New |
Product Description
DL40x2000 slant bed cnc lathe machine
1. Rigid cast-iron structure hardened (50-52HRC) and ground guarantee high precision and stability;
2. The machine bed is made of heat stabilized cast-iron;
3. A wide range of options and accessories allow the machine to be highly customized for very accurate and reliable machining;
4. Various configuration are available with spindles from ASA 5" to ASA 15",power up to 30kW and tuming length up to 3000mm;
Standard Configuration
5. 70° inclined bed split and box guide way;
6. spindle stepless speed;
7. 12-station hydraulic turret;
8. 15″ hydraulic Solid chuck and Hydraulic tailstock;
9. Lateral waste device and Closed-end protection;
Specifications | Unit | Parameter |
Swing over bed | mm | Φ800 |
Center distance | mm | 2000 |
Max. turning diameter(Shafts/ Discs) | mm | Φ550/750 |
Guide way type | mm | box-type |
Chuck size | mm | 15" |
Spindle nose |
| ISO A2-11 |
Spindle speed | rpm | 20~2000 |
Main spindle motor power(S6) | kW | 22(30) |
Spindle bore diameter | mm | Φ100 |
X-axis travel | mm | 375 |
Z-axis travel | mm | 2160 |
X-axis rapid traverse | m/min | 12 |
Z-axis rapid traverse | m/min | 16 |
Positioning accuracy | mm | (X)0.019(Z)0.040 |
Repeat positioning accuracy | mm | (X)0.0012(Z)0.015 |
Turret: number of stations | mm | 12 |
Tool size | mm | 32×25 |
Tailstock quill diameter | mm | ¢160 |
Tailstock quill travel | mm | 180 |
Tailstock taper | MT | 5 |
Machine size: L×W×H | mm | 5950×2358×2600 |
Net weight | T | 13 |
Pls send inquiry to me for optioanl accessories and other further information about such slant bed cnc lathe machines.
