CDE6266x3000 Cheap Conventional Metal Gap Lathe Machine

FOB Price

US$ 5,000 - 10,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DALIAN	Place of Origin	Liaoning, China
Model Number	CDE6266Ax3000 conventional metal gap lathe machine	After-sales Service Provided	Engineers available to service machinery overseas
Condition	New

CDE6266x3000 conventional metal gap lathe machine

Main Features

Such conventional metal gap lathe machine has following features:

Main Usage

Such conventional metal gap lathe machine has following usages:

It can machine inner circle, outer circle, and end and head surface, taper surface;
Gap lathe can process the deformation parts;
Function is including the drilling and reaming;
Threads cutting: Metric, inch, diametrical pitch, module thread;

Main Technical Data

Specifications	Unit	Parameter
Max. swing over bed	mm	660
Max. swing over carriage	mm	430
Max. swing over gap	mm	910
Width of guide way	mm	394
Dia. of spindle bore	mm	52
Distance between centers	mm	3000
Taper of center sleeve		Morse No.6
Spindle speed	rpm	11~1400/22speeds
Longitudinal feed	mm/rev	0.035~2.842
Cross feed	mm/rev	0.009~0.804
Metric thread	mm	0.5~240(66)
Inch thread	tpi	80~1/4(49)
Module thread	mm	0.25~120(57)
Diametrical pitch thread	DP	160-7-16 (50)
Section of tool shank	mm	25×25
Travel of top slide	mm	150
Max. travel of cross slide	mm	393
Pitch of longitudinal lead screw	mm	12
Travel of tailstock center sleeve	mm	150
Diameter of tailstock center sleeve	mm	75
Taper of tailstock center sleeve	Morse	Morse No.5
Main motor power	kW	7.5kW(50Hz) 5.5kW(60Hz)
Wooden case/Steel pallet	mm	4990×1150×1900/ 4800×1120×1610
Gross/net weight	kg	3393/2690

Free Std Accessories

Optional Accessories

Pls send inquiry to me for optioanl accessories and other further information about such conventional metal gap lathe machine.

Photos of Workshop:
