Cnc Milling Machine Vertical VMC7032

FOB Price

US$ 20,000 - 30,000 / Set

1 Set(Min. Order)

Port Qingdao Ningbo Shanghai Tianjin
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HIENCE	Place of Origin	Shandong, China
Model Number	VMC7032	After-sales Service Provided	Engineers available to service machinery overseas
Condition	New

Product Description

Configuration and specification

1. Control system: KND system, Optional SYNTEC LNC from Taiwan, GSK , SIMENES FANUC,

2.12 tool ATC

3.Three axis box way type, Option linear guide rail.

4.Taiwan BT40 spindle unit

5.Precision ball screw

6.Coolant system, Self lubrication system. Lighting system

Items	Details	Specifications
Table	Size	800mm×320m
	Travel of 3 axis	610/320/400mm
	Max, table load	400kg
T-slot	Size	3-14mm
T-slot	Center distance	100mm
Spindle	Spindle taper	BT40
	Spindle to guide	376mm
	Distance of spindle head to table	130-530mm
	Max speed	8000rpm
	Motor power	3.7/5.5kw
	Spindle drive	Belt transmission
Accuracy	Positioning accuracy	0.02mm
Accuracy	Repeatability	0.01mm
Axis motor	Power of X/Y/Z	1.2/1.6/1.6kw
Feeding speed	Rapid feed of X/Y/Z	1000mm/min
Feeding speed	Cutting feed of X/Y/Z	6000mm/min
Parameters	Air pressure	6Kgf/cm²
	Weight	1900kg
	Dimension	228017602300mm
	Package size	2450* 2100* 2450mm
	Power	3 phase 380V,

Our Company

Factory

Packing & Delivery

Packaging
Size	2450(L) * 2100(W) * 2450(D)
Weight	1900kg
Packaging Details	The normal package is wooden box(Size: LWH). the wooden box will be fumigated.
