ZIGBEE Wireless RTU Module for Monitor and Control
- Wuhan
- T/T L/C D/P D/A
- 7 days
You May Like
-
GPRS/CDMA DTU Modem With RS232/422/485 Serial Ports
-
MD-1110 Electric Parameter Module
-
Type XTZH-IIID Comprehensive Tester for Efficiency of Crude Gathering System
-
Model ZJK-I Intelligent Monitoring Unit of Water Injection Wells
-
ZJK-DXF Electronic High-Pressure Check Valve (Feedback)
-
ZJK-JY Pressure Reducing and Liquid Mixing Unit
Product Details
| Brand Name | Mind | Place of Origin | China | |
| Power | Electronic | Usage | Other, Oil testing |
Product Description
1.Features
★Signal reception mode 1: ZIGBEE wireless communication, comply with the ZIGBEE PRO communication protocol (ZIGBEE 2007 version agreement), communication distance is greater than 150 m ( empty area up to 300 m), instrument shell antenna end compatible with external antenna.
★ Signal reception mode 2: 485 wired communication, comply with the modbus communication protocol.
★Signal reception mode 3: 433 wireless communication.
★Signal emission mode: 485 or 232 wired communication, transfer with DTU.
★Support reading remote data.
2.Technique Data
★ Supporting devices: wireless work diagrams;Wireless temperature, wireless temperature, wireless pressure (zigbee or 433), wire parameter module, other modbus equipment.
★Power supply: 24V direct current
★Communication distance: zigbee mode, 300m (open area), 433HZ, 300m
★Environment temperature: -40℃～70℃
★ Relative humidity: 10% ～90%
★ Signal output mode: DTU upload(RS485 or RS232)
★ Signal input mode: zigbee, 433, RS485
★ Protocol: Modbus, four standard protocols, custom protocol
