Home > Products > Construction Hoist Elevator > Mast Hot-dip Galvanized , Painting Construction Hoist Elevator with Twin Cage 1600kg Capacity
Mast Hot-dip Galvanized , Painting Construction Hoist Elevator with Twin Cage 1600kg Capacity
- T/T L/C D/P D/A
- 7 days
You May Like
-
18 / 24 / 30 Passenger Construction Hoist Elevator , Material Hoisting Equipment
-
Easy Operated 2000kg Construction Hoist Elevator Industrial Material and Passenger
-
2000kg High Capacity Electric Construction Hoist Elevator Single Cage with 118kg mast section
-
Red Double Cage Construction Material Electrical Hoist 380V 50Hz , Industrial Hoists
-
VFC Control Construction Hoist Elevator with Rack , Construction Material Handling Equipment
-
Single / Twin Cage OEM Construction Hoist Elevator / Building Materials Handling Hoist
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | SC-series |
Product Description
Certification:CE,ISO
?
Mast Hot-dip Galvanized , Painting Construction Hoist Elevator SC 160 Twin Cages 1600kg Capacity?
?
?
?
Quick Detail:
?
|
Name |
Other Name |
Brand Name |
Control |
|
Construction lifting hoist |
Construction lifting hoist SC 160/160 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
1600kg/1600kg |
Certificate |
CE |
?
?
Description:
Construction lifting hoist SC 160/160 is installed and dismounted conveniently and can grow as high as the building grows height.The Construction lifting hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
?
?
Applications:?
SC serialization of products Construction lifting hoist is a Rack and Pinion EL. Construction lifting hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
?
?
Specifications
Standard?technical datas of? double cage?:
|
Parameter |
SC100/100 |
SC160/160 |
SC200/200 |
SC270/270 |
SC320/320 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(Kw) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Cage?inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Cage?weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
