CE and ISO Approved High Safety Construction Passenger Hoist for Industrial
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Customized Passenger or Material Construction Lifts Hoist 1600kg 12 - 38 Man
-
Rack and Pinion Construction Lifts Electric passenger material hoist for building site
-
2T Frequency Construction Lifts / Building Material Elevators with Single Cage
-
Rack and Pinion Hoist Construction Lifts 2700kg 3.2 x 1.5 x 2.5m for Warehouse
-
High Speed Construction Hoist Lifts 2.7T for Building Materials and Passenger
-
3200kg Material Lifting Construction Lifts Cage , Construction Hoist Elevator Machine
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | SC-series |
Product Description
Certification:CE,ISO
?
?
Rack / Pinion SC1600 Twin Cage Construction Lifts With 1600kg 3 x 1.4 x 2.5m
?
?
Quick Detail:
?
|
Name |
Other Name |
Brand Name |
Control |
|
Construction Lift |
Construction Lift SC 160/160 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
1600kg/1600kg |
Certificate |
CE |
?
?
Description:
?
Construction Lift SC 160/160 is installed and dismounted conveniently and can grow as high as the building grows height.The Construction Lift has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
?
?
Applications:?
?
SC serialization of products Construction Lift is a Rack and Pinion EL. Construction Lift widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
?
?
Specifications
Standard?technical datas of? double cage?:
|
Parameter |
SC100/100 |
SC160/160 |
SC200/200 |
SC270/270 |
SC320/320 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Cage?inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Cage?weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
?SAJ30-1.2 |
SAJ40 |
