24V Rack Mount CCTV Power Supply 10A 240W with 16 Channel, 24VAC10A16P/R
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
16 Channel Rack Mount CCTV Power Supply , 24 Volt AC Power Supply, 24VAC10A16P/R
-
16 CH CE Rack Mount CCTV Power Supply for CCTV Cameras , 240W 10A
-
240W Power Supply Rack Mount with PTC , 24VAC 10A 10 channel Power Supply Rack Mount
-
12VDC Rack Mount CCTV Power Supply 13A 156W with 16Channel,12VDC13A16P/R
-
16 CH Rack Mount 12VDC 13A CCTV Power Supply , Switch Power Supply
-
IEC Rack Mount CCTV Power Supply for Powering CCTV Cameras,12VDC 13A 16CH
Product Details
| Brand Name | Chinasky | Place of Origin | China | |
| Model Number | 24VAC10A16P/R |
Product Description
Certification:CE,RoHS
1.Output voltage: 24VAC±5%
2.Output current: 10A
3.Input Voltage: 110/220VAC
3.Power: 240W
4.Output type: 16 channels for 16 sets load
5.Certification: CE , IEC
6.Supply type: ODM
24V Rack Mount CCTV Power Supply 10A 240W with 16 Channel, 24VAC10A16P/R
Descrition:
The Rack Mount CCTV Power Supply 24VAC10A16P/R is designed with sixteen (16) individual fused outputs for powering CCTV Cameras and other video accessories. It will provide 24VAC via sixteen (16) fused outputs with a total of 10 Amp continuous supply current.
Features:
Power up to 16 CCTV CCTV surveillance cameras 24 Volts AC 10 Amp total output Max output current up to 1.1 Amp/Channel 16 individually PTC auto-reset fuses protected outputs Integral surge protection Individual LED power indication Individual PTC reset-able fuses Power ON/OFF switch (internal) Spare fuses included. Unit maintains camera synchronization Ease of installation saves time and eliminates costly labor Modular 1U standard EIA 19\" rack mount chassisTechnical specifications:
|
Model |
24VAC10A16P/R |
|
|
Power |
240W |
|
|
Metal Case Dimension |
48×25.2×7.5cm |
|
|
Net Weight |
5.6kgs |
|
|
Input |
Input Voltage |
110/220VAC |
|
Input Voltage Frequency |
50Hz-60Hz |
|
|
Output |
Output Voltage |
24VAC±5% |
|
Output Current |
10A, 16 channels for 16 sets load |
|
|
Fuse |
Type /Rating |
PTC? 13A/250V |
|
Protection |
Over Voltage Protection |
When over voltage occurs, it will switch to self-protection status to protect the load. |
|
Over Current Protection |
When over current occurs, the corresponding channel output will automatically switch to self-protection status, and the other channels output will work normally. When the fault is cleared, it will switch back to normal. |
|
|
Short-circuit Protection |
When short-circuit occurs, the individual PTC fuse will break the circuit. When the fault is cleared, it will switch back to normal automatically. |
|
|
Circumstances |
Working Temperature |
0℃-+50℃ |
|
Storage Temperature |
-20℃-+80℃ |
|
|
RH |
20%-90% |
|
|
Heat Release |
Natural heat dissipation |
Competitive Advantages:
This is one of the best 12VDC CCTV power supply boxes on the market for security cameras. We replace the cheap \"glass fuse\" with \"PTC\" Reset Fuses which will Auto Reset after you fix the short.?You don\'t have to run around town try to find the replacement fuses.?All you have to do is to fix the shorts. The red light shorts indicator helps you to know which camera is not working. Dependable and long lasting Warranty: 2 yearsContact Us
