Home > Products > Temper Rolling Mill > Hardened Temper Rolling Mill Four Roller For Carbon Steel High Elasticity
Hardened Temper Rolling Mill Four Roller For Carbon Steel High Elasticity
- T/T L/C D/P D/A
- 7 days
You May Like
-
Stainless Steel Tension Leveling Line For Steel Strip Edge Wave Removal
-
Hydraulic Electric Controller Copper Strip Rolling Mill High Efficiency
-
Casting Aluminium Rolling Mill , Cold / Hot Four High Rolling Mill Machine
-
Carbon Steel 6 Hi Cold Rolling Mill , Hydraulic Pressure Down Cold Rolling Machine
-
High Efficiency Electrolytic Cleaning Line For Removing Oil / Scrap Iron
-
Stainless Steel Four High Rolling Mill , Electric Reversible Rolling Mill
Product Details
| Brand Name | wuye | Place of Origin | China | |
| Model Number | 1000mm |
Product Description
Certification:ISO2000
Hardened Temper Rolling Mill Four Roller For Carbon Steel High Elasticity
Functions and applications
It consists of two series of two rollers and four rollers. It is used for leveling the annealed cold rolling strips in order to improve the machinery functions to enhance the surface hardness, strength and elasticity of Cr strips. Meanwhile, the CR strips through the leveler unit can have functions of excellent deep punching, shapes and surace clearness. Four-roller leveler unit for middle and wider coils and plates is equipped with hydraulic AGC pressing down and ?rolling line ?automatic adjusting device, The work rolls adopt hydraulic anti- bending electro-liquid servo system. At the front device and rear device equipped with?S roller, anti-crinkle rollers and anti-jumping rollers, which has the??functions of automatic threading and?easy operation. while computer on line control can realize constant extension, constant rolling force, constant roll gap, constant tension, etc.
Components:
uncoiler--hydraulic shear--entry S roller--entry anti-crinkle rollers--four-roller main temper mill--exit anti-crinkle rollers--exit S roller--coiler.
Technical parameters:
| type | φ350X400 | ? | φ450X550 | ? | φ550X650-750 | ? | φ280/φ580X800-900 | φ320/φ650X900-1000 | φ330/φ700X1200-1400 |
| strip thickness | 0.3-1.0 | 0.2-0.8 | 0.3-1.0 | 0.2-0.8 | 0.3-1.0 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 |
| strip width | 250-300 | ? | 350-450 | ? | 550-650 | ? | 700-800 | 700-900 | 1000-1200 |
| press down | electric | hydraulic | electric | hydraulic | electric | hydraulic | hydraulic | hydraulic? | hydraulic |
