Product Details
| Brand Name | Wuye | Place of Origin | China | |
| Model Number | 750mm |
Product Description
Certification:ISO2000
MKW 8 High Steel Rolling Mill Equipment 750mm AGC Electric Controller
1. technical specifications
Material:Stainless steel 304 201
Input thickness:≤1.0mm width =450～625mm
Output thickness: ≥0.14mm, width =450～625mm
Max. coil weight:10t
Max rolling force:5500KN
Rolling speed: ≤265m/min
ID/OD: Φ500/Φ1800mm
Daily capacity: 50-60t(550mm width, from 0.58mm roll down to 0.22mm, daily working 20 hrs.)
2. Main components:
1. Main rolling mill 1 set
2. Technical table 2 sets
3. roller-changing device 1 set
4. solid reel drum coiler 2 sets
5. hydraulic station 1 set
6. thin oil lubrication station 1 pc
7. coolant system(provided by user) 1 set
8. electric control cabinet 1 set
3. Product list
Machinery device| NO. | DESCRIPTION | UNIT | QT’Y | NOTE |
| 1 | Left s olid reel drum coiler | set | 1 | ? |
| 2 | Left device | set | 1 | ? |
| 3 | Housing(including roller assy, pressure down device, hydraulic balancing device, side supporting beam, rail, etc) | Set | 1 | ? |
| 4 | Right device | set | 1 | ? |
| 5 | Right solid coiler | set | 1 | ? |
| 6 | Main drive device | set | 1 | ? |
| 7 | Device of changing roller | set | 1 | ? |
| 8 | Pressure platform and stair, handrail | set | 1 |
excluding fan and pipes are provided by user. |
| 9 | Foundation bolts | set | 1 | ? |
2) DC Motor
| NO. | NAME | UNIT | QT’Y | SPC. |
| 1 | DC motor | ? | 4 | ? |
| 1.1 | Main motor | set | 1 | Z500-4A ,710kW |
| 1.2 | Motor in coiler | set | 2 | Z500-4A,500kW |
| 2 | photoelectric encoder | Pc | 5 | ? |
| 3 | Electric controller | ? | Complete set | ? |
| NO. | NAME | UNIT | QT’Y | NOTE |
| 1 | AGC pump station | set | 1 | ? |
| 2 | General hydraulic station | set | 1 | ? |
| 3 | Thin oil lubricating system | set | 1 | ? |
4) provided by user
| No | Name | QTY | Note |
| 1 | X ray thickness gauge | 2 | ? |
| 2 | Coolant system | 1 | 2500l/min |
