Low Noise Axial Flow Submersible Effluent Pump Cast Iron High Performance
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Axial Flow Ventilation Submersible Dirty Water Pump Single Stage With Motor Drive
-
Axial Flow Turbine Submersible Sewage Pump For Waste Water Treatment System
-
Vertical Portable Submersible Sewage Pump With Industrial Axial Flow Propeller
-
DIN 24255 High Pressure End Suction Centrifugal Pump , Fire - Fighting Water Centrifugal Pump
-
DIN 24255 Hydraulic Single Suction Centrifugal Pump End Suction Capacity 1660 m3/h
-
Simple Horizontal Close Coupled Centrifugal Pump Speed 1450rpm For Wastewater Treatment Plant
Product Details
| Brand Name | GSD | Place of Origin | China | |
| Model Number | ZDB/HDB |
Product Description
Certification:CE,ISO,SPAN,ECA
Low Noise Axial Flow Submersible Effluent Pump Cast Iron High Performance?
Application:
| 1 | water supply works and power station. |
| 2 | The Axial flow submersible electric pump applies to the condition of low lift head, high flow-rate; while the mixed-flow submersible electric pump is very efficient with high performance of cavitation erosion |
| 3 | The conveyance medium is untreated water or lightly polluted water. The highest temperature of the conveyed resolution is 40oC. |
Features:
| 1 | As its operation submerged into water, the electric pump can greatly simplify geotechnical engineering and building structure engineering of pump station, reduce erection space and save 30%-40% construction cost. |
| 2 | Due to the electric motor is combined with the hydraulic pump, the assembly procedure is no longer necessary for lining up axis of electric motor, transmission mechanism and hydraulic pump on site |
| 3 | Low noise, no high temperature in pump station, improving the operational environment and underground pump station can be built according to the requirement; as a result, the environment scene on the ground can be maintained. |
Model number description:
Structure of electric submersible pump:
ZDB submersible axial-flow pump is made up of submersible motor and axial-flow pump section. The motor and pump adopt direct connection, with voltage of 380V, 50HZ. The motor shaft extends from the lower cover, where a secondary mechanical seal is set together with oil seal in order to prevent water from flowing into the motor along the shaft.
The pump section consists of impeller, enclosure of impeller and guide vane unit. We design and provide corresponding installation system according to the practical situation of the pumping station.
The impeller of ZDB submersible axial-flow pump is semi-adjustable and the inner surface of the enclosure of impeller is spherical. When filling oil into the inner chamber of the guide vane, the oil storage shall not spill from the upper oil way of the oil chamber. There are two symmetrical holes in the sides of the guide vane, one is oil way and the other is vent hole. When filling oil, both holes shall be opened, one for oil filling and the other for air discharging. After the oil is filled in, screw down the two oil plugs. Examine whether the ring seal is damaged, and it must be replaced when damaged. Special anti-winding structure is used between the impeller and guide vane to prevent foreign matters from entering the pump and winding the impeller.
There is a sealed oil chamber inside the guide vane to act as a buffer for the leakage between motor and pump and to lubricate the mechanical seal.
Construction:
Performance parameter:
700ZDB-100J:
