8.1 5KA Silicone Rubber Distribution Surge Arrester Gray Export Type
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Polymeric Surge Arrester / Station Class Surge Arresters Red 51KV For Power System
-
12KV-15KV 100A PORCELAIN Drop Out Fuse Cutout / High Voltage Cut Out
-
Exported Suspension Type Composite Polymer Insulator Gray Color 11 Kv Post Insulator
-
GW1 Sires Air Break Switch Disconnector High Voltage For Transformer Protection
-
200A HV Porcelain Cutouts 12kV Drop-out Fuse Cutout -40oC~ +40oC
-
12KV Gray Color Composite Pin Insulator FPQ Type / Railroad Insulators
Product Details
| Brand Name | YIXIN | Place of Origin | China | |
| Model Number | YH5W |
Product Description
Certification:CE
8.1 5KA Silicone Rubber Distribution Surge Arrester Gray Export Type
Specifications:
| TYPE | Rated Voltage KV(rms) | Maximum continuous operation voltage KV (crest) | Max. Residual Voltage | 2000us Square wave current impilse withstand A (crest) | 4/10us High current impulse ka (crest) | ||
| Steep current impulse kv (creset) | Switching current impulse kv (creset) | Lightning current impulse kv (crest) | |||||
| ? | ? | ? | ? | ? | ? | ? | ? |
| YH5W-3 | 3 | 2.55 | 9.5 | 7.7 | 9 | 100 | 65 |
| YH5W-6 | 6 | 5.1 | 19 | 15.4 | 18 | 100 | 65 |
| YH5W-9 | 9 | 7.65 | 28.5 | 23.1 | 27 | 100 | 65 |
| YH5W-10 | 10 | 8.3 | 36.0 | 27.0 | 30 | 100 | 65 |
| YH5W-11 | 11 | 9.5 | 38.5 | 30.0 | 33 | 100 | 65 |
| YH5W-12 | 12 | 10.2 | 38.0 | 30.8 | 36 | 100 | 65 |
| YH5W-15 | 15 | 12.7 | 47.5 | 38.5 | 45 | 100 | 65 |
| YH5W-18 | 18 | 15.3 | 57.0 | 46.2 | 54 | 100 | 65 |
| YH5W-21 | 21 | 17 | 66.5 | 53.9 | 63 | 100 | 65 |
| YH5W-24 | 24 | 19.5 | 76.0 | 61.6 | 72 | 100 | 65 |
| YH5W-27 | 27 | 21.9 | 85.5 | 69.3 | 81 | 100 | 65 |
| YH5W-30 | 30 | 24.4 | 95.0 | 76.5 | 90 | 100 | 65 |
| YH5W-33 | 33 | 26.8 | 104.0 | 84.7 | 99 | 100 | 65 |
| YH5W-36 | 36 | 29 | 114.0 | 92.7 | 108 | 100 | 65 |
| YH5W-42 | 42 | 34.1 | 132.3 | 100.1 | 126 | 100 | 65 |
Description:
Arrester is a kind of overvoltage protector mainly applied for the protechtion of various electrical appliances (such as transformer, switch, capacitor, trap, mutual inductor, generator, motor and power cable etc.) in power system, railway electrification system and communication system from being damaged by atmosphere overvoltage, operation overvoltage and power frequency temporary overvoltage etc.
Advantage:
1. The low weight facilitates installation and permits erection in limited spaces and at almost all angles.
2. No continuous current and low current impulse residual voltage.
3. Excellent pollution and short circuit performance.
4. Safe to touch when energised by accident.
5. Stable U-I characteristics,even after multiple strikes.
6. Resistant to UV,ozone,chemicals,mechanical abuse.
7. Fully qualified following IEC60099-4.
