Home > Products > Sharp LCD Panel > Long Backlight Life 3.7 Inch Sharp LCD Panel Parallel RGB LS037V7DD06
Long Backlight Life 3.7 Inch Sharp LCD Panel Parallel RGB LS037V7DD06
Negotiable
/ Piece
1 Piece(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Professional 6 Inch Industrial Lcd Screen , Flat Panel Lcd Display TM060RDH01 400 Brightness
-
Low Power Consumption NEC LCD Panel 240 320 Resolution With Dot Matrix Lcd Display
-
Sunlight Readable 3.5 Inch NEC TFT LCD Panel NL2432HC22-23B For E-Ink Reader
-
Transflective 3.5 Inch NEC LCD Panel NL2432HC22-40A 6S1P WLED Without Driver
-
High Contrast Ratio 5.6\" Tianma LCD Module TM056KDH02 320 * 234 Resolution For Video Doorphone
-
WLED Lamp 3.5 Inch NEC LCD Screen NL2432HC22-41B , High Resolution TFT LCD Module
Product Details
| Brand Name | SHARP | Place of Origin | China | |
| Model Number | LS037V7DD06 |
Product Description
Certification:ISO9001
SHARP 3.7 inch LCD LS037V7DD06 Hard coating CG-Silicon , Panel
Technical parameters for SHARP LS037V7DD06:
<
1. Brightness : 100 cd/m2 (Typ.)
2. Contrast Ratio : 100:1 (Typ.)(Transmissive) 5:1 (Typ.)(Reflective)
3. Display Colors : 262K (6-bit)
4. Response Time : 30/50 (Typ.)(Tr/Td)
5. Viewing Angle : 40/40/40/40 (Typ.)(CR≥2) (L/R/U/D)
6. Lamp Type : WLED
7. Signal Interface : Parallel RGB (1 ch, 6-bit) , 51 pins
8. Input Voltage : 5.0/3.3/8.0/-4.0/-8.0V (Typ.)(VSHA/VSHD/VDD/VSSD/GVSS)
Our Product Advantages:
<
| Display Mode : | TN, Normally White, Transflective |
| Brightness : | 100 cd/m2 (Typ.) |
| Contrast Ratio : | 100 : 1 (Typ.) (Transmissive) |
| Contrast Ratio : | 5:1 (Typ.) (Reflective) |
| Display Color : | 262K (6-bit) |
| Response Time : | 30/50 (Typ.)(Tr/Td) |
| Viewing Angle : | 40/40/40/40 (Typ.)(CR≥2) (L/R/U/D) |
| Viewing Direction : | 6 o'clock |
| Reflectance Ratio : | 4/6% (Min.Typ.) |
| Sunlight Readable : | Sunlight Readable |
Industrial standard- and semi-custom panels also available as complete display-kit solution including Display Solutions developed high quality and long-term available TFT LCD panel or Touch Screen.
We are professional Industrial Panel Distributor of the following manufacturers: AUO, LG, Innolux, Sharp, NEC, BOE and More.
Specifications:
?custom original industrail lcd display
1. customized is welcome
2. fast delivery time
3. ISO 9001 certificate
4. small size
Descriptions for SHARP LS037V7DD06:
<
| Lamp Position : | Edge light type |
| Lamp Type : | WLED |
| Lamp Shape : | 1 string |
| Lamp Voltage : | 32.4/37.8V (Typ./Max.) |
| Lamp Current : | 15/20mA (Typ./Max.) |
| Lamps Power Consumption : | 486mAW (Typ.) |
| Interface Type : | Included in panel signal interface |
Details Pictures for?SHARP LS037V7DD06:
