Antiglare 10.1 Inch Chimei LCD Panel High Brightness With Full View Angle N101ICG-L21
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Brightness 8.0 Inch Innolux LCD Panel HE080IA-06B With Hard Coating
-
Transmissive LCD Display Panel 1024 600 , Innolux 7 Inch LCD HJ070NA-01U For Medical
-
Hard Coating 10.1 Inch Innolux LCD Panel EJ101IA-01G Display Mode With IPS / Transmissive
-
High Resolution Innolux LCD Panel 8 Inch Normally Black For Handheld Devices
-
8.0 Inch A-Si TFT Lcd Panel WLED Without Driver For Control Room 1024 768
-
Original 3.5 Inch Samsung LCD Panel LTV350QV-F04 For Industrial / Commercial
Product Details
Brand Name | Chimei | Place of Origin | China | |
Model Number | N101ICG-L21 |
Product Description
Certification:ISO9001
Antiglare 10.1 Inch Chimei LCD Panel High Brightness With Full View Angle N101ICG-L21
Chimei?N101ICG-L21 Optical Features:
Panel Size : | 10.1 inch |
Dot Resolution : | 1280(RGB)×800 (WXGA) |
Pixel Configuration : | RGB Vertical Stripe |
Pixel Density : | 149 PPI |
Aspect Ratio : | 16:10 (H:V) |
Form Factor : | Flat Rectangle Display |
Dot Pitch : | 0.0565×0.1695 mm (H×V) |
Pixel Pitch : | 0.1695×0.1695 mm (H×V) |
Weight : | 120/135g (Typ./Max.) |
Surface : | Glare (Haze 0%), Hard coating (3H) |
Active Area : | 216.96×135.6 mm (H×V) |
Bezel Area : | 219.31×138.25 mm (H×V) |
Outline Dimension : | 227.42×147.69 mm (H×V) |
Outline Depth : | 2.16/4.85 (Typ./Max.) mm |
Holes & Brackets : | Without |
Landscape or Portrait : | Landscape type |
Touch Panel : | Without |
Museum, Bank, Restaurant, Airport, Shopping mall,Exhibition ,Railway station, Police office, Control room, Studio room. All the places where require high display advertisement or Security surveillance.
Our Company Advantage in Industrial LCD Panel:?
??? N&S Electronics Co., LTD, ?integrated LCD touch display solutions, which will make the process of your development easy. The module seals LCD, touch screen, the foundation hardware and software (driver), and universal connection (USB or RS232) to PC and embedded system.We focuses on LCD display module integrate touch screen in medium and small size between 5~12.1 inches. Touch screen technology is the most popular form in applications ranging from industry to consumer . It is more convenient compaired with key button control technology. The input signal includes HDMI, AV, VGA, S-video, DVI, YPbPr and 3G-SDI, etc.
Competitive Advantage:?
1. ? We are a leading manufacturer of LCD products for more than 10 years.
2.?? We got the ISO9001 quality management system certification.
3.?? We have our own R&D team, and accept OEM order as per customer’s design.
4. ? We are the 5-years four star member of Globalsources and the Three year Gold supplier in Alibaba.
5.? Our main material LCD panels all are directly imported from Samsung and LG in Korea.
6. ? All products win the certificate of CE,CCC,FCC and RoHS.
7.?? Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 5 days.
8. ? 3-years warranty is offered.
Applications for?Chimei LCD Panel ,? N101ICG-L21:?
Mainly Used in Closed-Circuit Surveillance Systems
Car Video, PC Operating Systems
Vehicle Navigation Systems Supporting Display
Can Also be Applied for Industrial Automation
Medical Machine Equipments
Electric Power
Petrification
Monitor
Navigation
POS, ATM and Instrumentation Display Systems
Details Picture for the?N101ICG-L21?LCD Screen Display Panel:
