Aluminium Long Span Corrugated Sheet Making Machine 900-1200 Meters / Hour
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Strength Corrugated Steel Roof Panel Roll Forming Machine
-
Steel / Aluminium Roof Panel Roll Forming Machine 380V / 50HZ
-
Cameroon Aluzinc Roof Panel Roll Forming Machine Corrugated Sheet Making Machine
-
Hot Dipped Galvanized Steel Strip Purlin Roll Forming Machine With Decoiler
-
Galvanised Steel C Profiled Purline Roll Former Machine With Cr12 Mould Steel Rollers
-
IT5 Roofing Corrugated Sheet Roll Forming Machine With Five Industrial Trough
Product Details
Brand Name | Creation | Place of Origin | China | |
Model Number | CYX-25-198-1200 |
Product Description
Certification:ISO 9001:2008, CE, SONCAP
Corrugated Aluminium Long Span Roofing Sheet Corrugating Machine with Forming Speed 900-1200 Meters per Hour
Features of Longspan Roof Sheets Corrugating Machine: |
1. Cutter Material: Cr12 mould steel with heating treatment |
2. Shaft Material: #45 steel with quenching treatment |
3. Roller Material: #45 steel with quenching treatment, then coated with hard chrome |
4. Have fashionable, nice appearance and durable |
5. Delivery time: around 60 working days |
6. Full automatic production |
7. All our machines are designed and manufactured according to customers' requirement |
Technical Parameters of Longspan Roof Sheet Corrugating Machine | ||
1 | Machine name | long span roof forming machine |
2 | Machine dimension (mm) | 9000*1600*1500 |
3 | Total wight (Kg) | 9500 |
4 | Forming steps | 20 |
5 | Forming speed (m/min) | 15-20 |
6 | Main driving motor power(Kw) | 7.5 |
7 | Diameter of rolling shaft (mm) | 72 |
8 | Hydraulic pressure(MPa) | 10 |
9 | Electric condition | 380V/3Phase/ 50HZ |
10 | Power for hydraulic decoiler(Kw) | 5.5 x 2 |
11 | Decoiler max capacity (Kgs) | 5000 |
12 | Control system | Mitsubishi PLC |
13 | Raw material thickness (mm) | 0.3-0.7 |
14 | Effective width(mm) | 1000 |
15 | Material width(mm) | 1200 |
Working Flow of Longspan Roof Sheet Corrugating Machine
Decoiling---->Sheet Guilding---->Corruating---->Cutting---->Finished Roof Sheets on Supporters
? | Main Components | Main Description |
1 | Automatic hydraulic uncoiler(according the machine and your requirement) | 1.Loading Capacity: 5-10 tons |
2.Main motor: 5.5 KW x 2 | ||
3.Coil Width:Max: 1250mm | ||
2 | Entry Bench | Guiding the raw material into the roll forming machine smoothly |
3 | Feeding Section with guide | Easily for the raw material entry |
4 | Main roll forming machine | Forming the panel according your requirement |
5 | PLC control system | Automatically control the quantity of sheet, cutting length |
6 | Cutting blade | Cutting the panel automatically |
7 | Product Rack | Can adjustable according the length of the panel |
8 | Pressing device | Pressing the panel automatically |
9 | Mesh safety cover on roll former (optional) | For safety |
