Automatic High Rib Roof Corrugated Sheet Roll Forming Machine 1200mm 1220mm

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Creation		Place of Origin	China
Model Number	CYX-32-250-1200

Product Description

Delivery Time:60 working days after received your deposit payment
Certification:ISO 9001:2008, CE, SONCAP

Colored High Rib Steel Roofing Sheet Profiling Machine with Mitsubishi PLC Controller and 5 Tons Decoiler

The roof sheets manufacturing?machine?is making coloured steel & aluminum roofing sheets with?higher ribs to get a stronger roof application.

Machine Features:?

1. Precise Forming?
2. High-solid forming stand guarantees a?good and uniform high quality of final products?
The operation automatically minimizes the tolerance of cutting length?

Main Components

?3 Tons Uncoiler	?1 Unit ? ? ??
?Direction Guilder	?1 Unit
?Roll Former Machine	?1 Unit???????????????????????????????????
?Step Presser	?1 Unit
?Cutting Device ? ? ? ? ? ? ? ? ? ? ??	?1 Unit
?Mitsubishi PLC Controller	?1 Unit
?Conveyors	?2 Units

Technical Specifications of Color Coated Hi Rib Roofing Sheet Roll Forming Machine

Technical Items		Details
Raw Material	Type	Aluminium & Steel Coils, PPGI, GI, PPGL
	Width	1200 mm, 1220mm
	Thickness	0.3-0.7?mm
	Yield Strength	235-345 MPa or specially designed for 550 MPa
Finished Products	Cover width	1000 mm
Finished Products	Length	Adjustable
Required Power	Voltage	220V/380V/415V/440V
	Driving Motor	7.5 KW
	Cutting Motor	2.2 KW
Production Speed		900-1200 meters per hour
Coil Decoiler	Type	Un-powered or Powered
Coil Decoiler	Capacity	5 tons
Rolling Stations		21?sets
Rolling Shaft Diameter		72 mm
Cutting Type		Post-cutting
Operation System		Mitsubishi PLC, transducer and touching screen
Supporting Tables		2 sets
Machine Size		Around 9.2?x 1.6 x 1.5 meters
Machine Weight		Around 9.2?tons

Manufacturing Progress of Roof Sheet Rolling Machine

Applications:

The steel high?rib roof sheets profiled?by this rollforming?machine are with a?long life performance with low maintenance
