Blue 125m SC Fiber Optic Fast Connector 0.3dB Field Installable Without Splicing
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Hybrid Single Mode Fiber Optic Attenuator 10dB 1550nm High Return Loss LC Adapter type
-
Cassette PLC Splitter 1x8 Module for Optical Distribution Box High reliablity
-
SM FTTH Fiber Optic Fast Connector Concentering SC Fibre Connectors 3.0x2.0 mm Cable
-
3.0mm Filter Wavelength Division Multiplexer for CATV Triple Optical Network
-
LC / UPC SM Fiber Optic Fast Connector , Single Mode Fiber LC Connector
-
Custom CWDM DWDM OADM LGX Box Module for Standard 3U Rack Mount
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Blue 125μm SC Fiber Optic Fast Connector 0.3dB Field Installable Without Splicing?
Fast fiber optic connector can provide a quick and easy termination of fibers in the field and options are available for 900um to3.0mm cable. Allowing the installer to terminate and make connection in minutes at equipment and fiber patch panels. This connector system removes any requirement for epoxy, adhesives or costly curing ovens.
Features
Made on-site without splicing connectors ;? Field installable Metal V-shape cavity work well in high and low temperature? Installation less than 1 minutes? Reliable and superior optical performance?Application
FTTH project usable? Fiber cable field quick repairTechnical Specification
|
Item |
Technical Data |
|
Cable type |
3.1×2.0 mm drop cable |
|
Connector type |
SC/APC? or SC/UPC |
|
Fiber dimension |
125μm |
|
Cover dimension |
900μm |
|
Fiber type |
SM |
|
Insertion loss |
0.3dB,max 0.5dB(1310nm&1550nm) |
|
Return loss |
UPC ≥50dB APC≥60dB |
|
Tensile strength |
>50N |
|
Operating temperature |
-40°C ~+75°C |
|
Storage temperature |
-40°C ~+80°C |
|
Temperature cycling |
IL change≤0.3dB,RL change≤5 dB |
|
Vibration |
IL change≤0.3dB,RL change≤5 dB |
|
Low Temperature Storage-40°C |
IL change≤0.3dB,RL change≤5 dB |
|
Damp Heat,85°C,85%H |
IL change≤0.3dB,RL change≤5 dB |
|
Tensile test online 20N |
IL change≤0.2dB,RL change≤5 dB |
|
Mechanical durability 500times |
IL change≤0.2dB,RL change≤5 dB |
