FC / UPC Single Mode Fiber Optic Patch Cord 12 Core Fiber Patch Cable
- T/T L/C D/P D/A
- 7 days
You May Like
-
1000M SFP Fiber Single Mode Transceiver LR 20km 40km 80km Available
-
CATV FC / PC - SC / PC Optical Fiber Optic Attenuator Single Mode Male To Female Hybird Type
-
Ethernet Networks Fiber Optic Attenuator 10dB Fiber Optics Attenuation
-
1dB - 30dB Single Mode Fibre Optical Attenuator 1550nm Fiber Attenuation Ethernet Networks
-
TLC Optical Attenuator Plug In Fixed Adapter Type / Single Mode fiber 8dB Attenuations
-
Fiber Optic Cable Patch Cord / Single ModeFiber Optic Patch Cord SM G652D 3.0mm Cable
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
?FC / UPC Single Mode Fiber Optic Patch Cord 12 Core Fiber Patch Cable
Fiber Optical patch cord is also known as optical patch cable or fiber jumper cables. It is widely used for the connection between outlets and terminal equipments. The patch cord is flexibility with small size and can be duplicate used, popular with low insertion loss and competitive cost. It is a indispensable components during the whole fiber optical network systems. SC/UPC fiber optical pigtail are widely use to fiber optical distribution box and other optical network systems.
Features
Single Mode or Multi-mode cable available Simplex and duplex cable type optional Low insertion loss and ultra low back reflection Telecordia GR-326-CORE Compliant Customized specification are availableApplication
High bit data transmission Telecommunication equipment Test instruments Active device terminations LAN/WAN and FTTXSpecification
|
Fiber Type |
Connector Type |
Polishing Type |
IL |
RL |
|
Single mode |
FC, SC, LC, ST, E2000, DIN, D4, MU |
PC |
<0.2dB |
>50dB |
|
FC, SC, LC, ST, E2000, DIN, D4, MU |
UPC |
<0.2dB |
>55dB |
|
|
FC, SC, LC, ST, E2000, DIN, D4, MU |
APC |
<0.2dB |
>60dB |
|
|
MTRJ, MPO, ESCON, FDDI |
/ |
<0.5dB |
>35dB |
|
|
Multi mode |
FC, SC, LC, ST, E2000, DIN, D4, MU |
PC |
<0.3dB |
>30dB |
|
MTRJ, MPO, ESCON, FDDI |
/ |
<0.5dB |
>30dB |
Order Information? A/B-C/D-E-F-G-H
|
A |
B |
C |
D |
E |
F |
G |
H |
|
A Connector |
Polishing Type |
B Connector |
Polishing Type |
Fiber Type |
Pigtail Type |
Pigtail Length |
Fiber Number |
|
FC, LC, SC, ST, MU, MTRJ, E2000, DIN, D4, SMA, ESCON, FDDI, MPO etc. |
UPC |
FC, LC, SC, ST, MU, MTRJ, E2000, DIN, D4, SMA, ESCON, FDDI, MPO etc. |
UPC |
SM= SMF-28e |
01=250um |
0.5=0.5m |
SX=Simplex, |
|
M5=MM50/125 |
09=900um loose tube |
10=1.0m |
DX=Duplex |
||||
|
M6=MM62.5/125 |
90=900um tight buffer |
15=1.5m |
00= OEM |
||||
|
00=other |
20=2.0mm cable |
20=2.0m |
|||||
|
30=3.0mmcable |
S= OEM |
