Home > Products > Fiber Optic Fast Connector > 250um Bare Fiber Connector Quick Optical Connections Pre Polishing 50N Tensile Strength
250um Bare Fiber Connector Quick Optical Connections Pre Polishing 50N Tensile Strength
- T/T L/C D/P D/A
- 7 days
You May Like
-
100G 8ch Dense Wavelength Division Multiplxing DWDM Mux Module
-
1620 nm Fiber Coarse Wavelength Division Multiplexing 8 to 1 High wavelength stability
-
Metal Single Mode Optical Connections Fiber Connectivity SC Fast Connector V - shape
-
Assembly ABS SC Optical Fibre Cable Connectors Reliable Embedded Data Quick Field
-
Single ModeFiber DWDM Dense Wavelength Division Multiplexing Optics 18 channel Passive Optical Equi
-
Fiber Dense Wavelength Division Multiplexing DWDM Module 200G Wavelength Add Drop Multiplexer
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
250um Bare Fiber Connector Quick Optical Connections Pre Polishing 50N Tensile Strength?
Bare Fiber?Fast connector?
can?provide?a?quick?and?easy?termination?of?fibers for fiber optical devices test and connection , are available for 250um single mode and milti mode fiber.?
Allowing?the?installer?to?terminate?and?make?connection?in?minutes at?equipment?and?fiber?patch?panels.?
This?connector?system?removes?any?requirement?for?epoxy, adhesives?or?costly?curing?ovens. Pre-polishing , Low loss and Relaible quality made it very popular in FTTH project and other cabling solutions .
Features?
Made?on-site?without?splicing?connectors?;? Field?installable Metal?V-shape?cavity?work?well?in?high?and?low?temperature? Installation?less?than?1?minutes? Reliable?and?superior?optical?performance?Application
FTTH?project?usable?? Fiber?cable?field?quick?repairTechnical?Specification:
|
Item |
Technical?Data |
|
Cable?type |
3.1×2.0?mm?drop?cable |
|
Connector?type? |
Bare Fiber Fast Connector |
|
Fiber?dimension? |
125μm |
|
Cover?dimension |
900μm |
|
Fiber?type? |
SM |
|
Insertion?loss |
0.3dB,max?0.5dB(1310nm&1550nm) |
|
Return?loss |
UPC?≥50dB?APC≥60dB |
|
Tensile?strength? |
>50N |
|
Operating?temperature? |
-40°C?~+75°C |
|
Storage?temperature |
-40°C?~+80°C |
|
Temperature?cycling? |
IL?change≤0.3dB,RL?change≤5?dB |
|
Vibration? |
IL?change≤0.3dB,RL?change≤5?dB |
|
Low?Temperature?Storage-40°C? |
IL?change≤0.3dB,RL?change≤5?dB |
|
Damp?Heat,85°C,85%H |
IL?change≤0.3dB,RL?change≤5?dB |
|
Tensile?test?online?20N |
IL?change≤0.2dB,RL?change≤5?dB |
|
Mechanical?durability?500times |
IL?change≤0.2dB,RL?change≤5?dB |
