Home > Products > Single Phase Power Source > 220V AC, 50 / 60 / 400HZ Frequency Conversion AC Single Phase Power Sources
220V AC, 50 / 60 / 400HZ Frequency Conversion AC Single Phase Power Sources
Negotiable
/ Kilogram
1 Kilogram(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Adjust Ultrahigh Precision Variable Frequency AC single phase Power Sources 3KVA
-
2KVA 220V / 50Hz / 60Hz Adjustable Frequency AC single phase Power Source
-
Stationary Single Phase & Three Phase Energy power Meter Test Bench
-
Portable power electricity single phase energy meter test bench high accuracy
-
Three phase energy meter test bench, easy operation, power 24 meter position
-
Power water meter test bench DN15~50,high reliablility high precision
Product Details
| Brand Name | CENN | Place of Origin | China | |
Product Description
Certification:CCC, CE, RoHS, UL
220V AC, 50 / 60 / 400HZ Frequency Conversion AC Single Phase Power Source
In: 220VAC 50/60HZ?
Out: 220VAC, 50/60/400HZ?
400hz For Military/Aircraft?
1 Phase Frequency Conversion AC Power Source
1phase intput 1phase output
Input: 220VAC 50/60HZ
Output: 220VAC, 50/60/400HZ
Output High Voltage: 0-300VAC
Output Low Voltage: 0-150VAC
400hz For Military and Aircraft
Capacity: 0.5KVA-100KVA
Information:
The?1 Phase Frequency Conversion AC Power Source is the mainstay of aircraft ground support and are designed to meet such power requirements of military, commercial aircraft as well as 400Hz avionics.
1 Phase Frequency Conversion AC Power Source which convert 60Hz or 50Hz electrical power to 50Hz, 60Hz, or 400Hz electrical power to run your equipment
Specification:
| Model (YK-BP) |
88- 005 |
8801 | 8802 | 8803 | 8805 | 8810 | 8815 | 8820 | 8830 | 8845 | 8860 |
88- 100 |
|
|
Rated capacity (KVA) |
500 | 1 | 2 | 3 | 5 | 10 | 15 | 20 | 30 | 45 | 60 | 100 | |
| Circuit mode | IGBT/PWM | ||||||||||||
| AC input | Single-phase 220V/50Hz,60Hz | Tri-phase 380V/50Hz,60Hz | |||||||||||
| AC output | Phase | Single phase ? | |||||||||||
| voltage |
Low range |
0V~150V | |||||||||||
|
Low range |
0V~300V | ||||||||||||
| Frequency | 400Hz | ||||||||||||
| Max Current |
0V~ 150V |
4.2A | 8.4A | 16.8A | 25A | 42A | 84A | 126A | 168A | 250A | 375A | 500A | 834A |
|
0V~ 300V |
2.1A | 4.2A | 8.4A | 12.5A | 21A | 42A | 63A | 84A | 125A | 188A | 250A | 417A | |
| Frequency stability rate | ≤±0.1% | ||||||||||||
| Load stability rate | ±0.5% | ||||||||||||
| Waveform distortion | ≤2%(linear load) | ||||||||||||
| Respond time ? | Max 2ms | ||||||||||||
|
Indication resolution? Indication resolution |
Digit frequ- ency |
4 digit??resolution 0.1Hz | |||||||||||
|
Digit? voltage |
4 digit??resolution 0.1V | ||||||||||||
|
Digit current |
4 digit??resolution ?below 4A:0.001A?? above 4A:0.01A | ||||||||||||
|
Digit power |
4 digit??resolution below 200W:0.1W ??above 200W:1W | ||||||||||||
|
Digit frequ- ency |
4 digit??resolution 0.001 | ||||||||||||
| Protector | Input no fuse switch, output fuse switch, electronics circuit speed detect the over voltage, over current, over load, over temperature, short circuit and automatic jump protection and alarm. | ||||||||||||
| Cooling | Forced fan cooling | ||||||||||||
| Environment ? |
Operate temper- ature |
0°C~45°C | |||||||||||
| Related humility | 0~90%(non condensing ) | ||||||||||||
| External dimension H*W*D(mm) | 187*428*440 |
650*430 *520 |
900* 450* 710 |
