Multilayer Linear Contact galvanised wire rope 6 x 103 FSNS for Ratory Driller
- T/T L/C D/P D/A
- 7 days
You May Like
-
Ratory Drilling Rig Rotation Resistant Linear Contact Wire Rope 6 x 109 WSNS
-
Compacted stranded wire rope high performance 6 x 111 WSNS
-
Construction Abrasion Resistant Linear Contact Wire Rope 8 x 25 Fi
-
FC / IWR wire ropes for lifting , compact wire rope 8 x 26 WS
-
Equal Rope Lay Length Parallel Laid Wire Rope 8 x 31 Warrington Seale Combined
-
8 x 36 WS Linear Contact Wire Rope Abrasion Resistant high strength wire rope
Product Details
| Brand Name | INCHTIGHT | Place of Origin | China | |
Product Description
Certification:Lloyd’s/CCS/ABS/BV/DNV
Multilayer Linear Contact ?galvanised wire rope 6 x 103 FSNS for Ratory Driller
About Linear Contact Parallel Laid Wire Rope
The Linear Contact Wire Rope (also named as Parallel Laid Rope) is one manufactured to form linear contact between stands by winding all wires at the same pitch.
The linear contact between wires of each layer causes the abrasion between wires to be low.
There is less variation in product because each layer is twisted with linear contact.? There are no hollow sections.
The breaking load is higher than Cross Laid Ropes of the same size because the effective cross section is higher.
Application
Various equipment for hoisting, derricking, lifting, towing, port load and unload, blast furnace hoisting and oil well drilling. The rope with wire core can be used under the shock load, heated and squeezed conditions.
Specifications
|
Nominal Diameter |
Approx.Weight |
Nominal Tensile Strenght of Rope (Mpa) |
||||||||||
|
1570 |
1670 |
1770 |
1870 |
1960 |
||||||||
|
Minimun Breaking Load of Rope |
||||||||||||
|
D |
FC |
IWR/IWS |
FC |
IWR/IWS |
FC |
IWR/IWS |
FC |
IWR/IWS |
FC |
IWR/IWS |
FC |
IWR/IWS |
|
mm |
kg/100 |
(KN) |
||||||||||
|
60 |
1370 |
1570 |
1800 |
1960 |
1910 |
2080 |
2030 |
2200 |
2140 |
2330 |
2240 |
2440 |
|
62 |
1460 |
1670 |
1920 |
209*0 |
2040 |
2220 |
2160 |
2350 |
2290 |
2490 |
2400 |
2610 |
|
64 |
1560 |
1780 |
2040 |
2230 |
2180 |
2370 |
2310 |
2510 |
2440 |
2650 |
2550 |
2780 |
|
66 |
1660 |
1890 |
2170 |
2370 |
2310 |
2520 |
2450 |
2670 |
2590 |
2820 |
2720 |
2950 |
|
68 |
1760 |
2010 |
2310 |
2510 |
2460 |
2670 |
2600 |
2830 |
2750 |
2990 |
2880 |
3140 |
|
70 |
1860 |
2130 |
2450 |
2660 |
2600 |
2830 |
2760 |
3000 |
2910 |
3170 |
3050 |
3320 |
|
72 |
1970 |
2260 |
2590 |
2820 |
2750 |
3000 |
2920 |
3170 |
