Heavy Duty Machine Swaged Soft Loop Wire Rope Slings with Galvanized Surface

Heavy Duty Machine Swaged Soft Loop Wire Rope Slings with Galvanized Surface

About Wire Rope Slings

Wire rope slings are a basic material handling tool and are the most frequently used type of sling in industry today. They offer a strong, dependable and economical option for most lifting applications. Their popularity is enhanced by the numerous sling configurations available to support a broad range of applications. These configurations include single and multi-part slings (such as round braids, flat braids, Tri-Flex and cable laid slings), grommets, single leg slings, multiple leg bridles, and a wide variety of fittings and attachments.

Relative to other types of slings, wire rope slings are average in strength/weight ratio, average in abrasion and cut resistance, poorest in elongation and flexibility, and average for high temperatures (IWRC only).

Features

A?mechanical?(or flemish)?splice sling?is most frequently used and is fabricated by unlaying the rope body into two parts, one having three strands, the other having the remaining three strands and core. The rope is unlayed far enough back to allow the eye to be formed by looping one part in one direction and the other part in the opposite direction and laying the rope back together.?
The strands are rolled back around the rope body and a metal sleeve is slipped over the ends and pressed (or swaged) to secure the ends to the sling body. A hydraulic swaging press with special dies is used to bond the sleeve in place. Extreme pressure forces the steel sleeve to flow into the voids between the wires and strands, creating an assembly that maintains most of the wire rope\'s nominal breaking strength.
?

Why INCHTIGHT?

As a professional wholesaler and manufacturer for wire rope slings and assemblies, INCHTIGHT has been the No.1 wire rope and sling supplier in Qingdao area. Our customers include ship building, military, construction and lifting service providers. With swaging machine up to size 120mm and experienced splicing workers, we provide strongest and safest wire rope slings. Also our sales staffs are professional with lifting equipment, and could provide with customer correct wire rope and slings for their equipment or lifting requirements.

Applications

1.Steel wire ropes with diameters from ?5 to ?60 are 6x371670N/mm2 type complying to GB/T20118 standard.

2.Values \"A\" or \"B\" can be customized. Otherwise, the values in the table apply.3.\"L\" value meets client requirements; n=5 and n=6 are safety factors, determined by users.

Specifications
