Mining Strand Steel 6 x 19 wire rope Flattend Triangular with more contact points

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 0 per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

INCHTIGHT

Place of Origin

China

Product Description

Delivery Time:within 30 days
Certification:Lloyd’s/CCS/ABS/BV/DNV

Mining Strand Steel ?6 x 19 wire rope Flattend Triangular with more contact points

About Flattened Strand Wire Rope

Flattened Strand Wire Rope (also called triangular strand), perform exceptionally well on certain installations, especially those involving heavy loads where the speed of operation is slow, where adequate diameter sheaves and drums are used, or where a crush resistant rope is required.

Their distinguishing physical feature is their relatively flat exposed surfaces of strands. As a result, the rope exterior is more nearly a smooth, continuous circle than that of regular round strand wire rope. Flattened strand ropes are made with two layers of 12 wires around a triangular-shaped center.

Features

The flattened shape forms a bearing surface with more contact points on each strand than a round strand rope. With more sheave contact, weight and wear on the rope are distributed more uniformly than on a typical round strand rope. The triangular strand structure also results in more steel in the cross-section than a standard round strand rope of equal size.

Specifications

Nominal Diameter	Approx.Weight	Nominal Tensile Strenght of Rope (Mpa)
1670	1770	1870	1960	2160
Minimun Breaking Load of Rope
D	NF	SF	IWR/IWS	FC	IWR/IWS	FC	IWR/IWS	FC	IWR/IWS	FC	IWR/IWS	FC	IWR/IWS
20	165	162	175	236	250	251	266	266	282	281	298	294	312
22	199	196	212	285	302	303	322	321	341	339	360	356	378
24	237	233	252	339	360	361	383	382	406	404	429	423	449
26	279	273	295	339	360	361	383	382	406	404	429	423	449
28	323	317	343	462	490	491	521	520	552	550	584	576	612
30	371	364	393	530	562	564	598	597	634	631	670	662	702
32	422
